This is the White variant of the Capacitive Touch Switch HTTM Touch Button Sensor Module- White in Electronic Switches/Keypads Modules. Available at ₹99.12 (₹84.00 + GST) with free shipping across India.
Looking for Capacitive Touch Switch Module White? Capacitive Touch Switch HTTM Touch Button Sensor Module- White is available at Zbotic with fast shipping across India.
Applications:
- Range hood operation panel
- Touch switch
- Handheld home air environment detector
- The keyboard of the industrial control device with waterproof function
- Car equipment
- Bluetooth test stand information display
Features:
- No mechanical components, don’t wear out, an infinite life, reduce maintenance cost;
- Its sensing part can be placed into any insulation layer (usually a glass or plastic material), it is easy to make and surroundings are sealed the keyboard, to play the role of moistureproof and
- waterproof;
- The panel design follows one’s inclinations, arbitrary button size, shape, design, characters, trademarks, such as the perspective window arbitrary collocation, make product integral feeling is stronger;
- Compared with physical keys, touch keys are less likely to damage;
- You can change on the back of the resistance, adjust the signal output is latched output or keep output (see 3.3.2 rainfall distribution on 10-12);
- 2.7 V ~ 6 V input voltage range-wide, 3.3 V output signal, can be directly used to drive the relay, optical coupling, LED lights, such as the original;
- – 30 ~ 70 ‘C temperature range of work;
- A touch-sensitive, no lag, time delay, flash and other adverse reactions;
- The built-in anti-jamming algorithm has good anti-interference performance.
Package Includes:
1 x Capacitive Touch Switch HTTM Touch Button Sensor Module- White
Capacitive Touch Switch HTTM Touch Button Sensor Module- Overview
The Capacitive Touch Switch HTTM Touch Button Sensor Module–White is a compact, solid-state touch-button interface designed for direct integration into electronic projects and control panels. It replaces mechanical push-buttons by sensing fingertip capacitance, offering long service life and reliable anti-interference performance.
Key Features of Capacitive Touch Switch HTTM Touch Button Sensor Module-
- Operating voltage range: 2.7 – 6 V DC for versatile system compatibility
- Output pin delivers 3.3 V ± 0.1 V with up to 500 mA load capacity
- Solid-state design with no moving parts reduces wear and maintenance
- Wide working temperature: 30 – 70 °C for stable operation in varied environments
- Anti-interference capability ensures accurate touch detection
- Can be mounted behind non-conductive panels for hidden or waterproof interfaces
- Genuine product, fast shipping from Zbotic across India
Applications and Use Cases
- Touch control panel for kitchen range hoods and cooker vents
- User interface switch on home appliances like air purifiers and humidifiers
- DIY electronics projects with Arduino or Raspberry Pi
- Industrial control panels requiring durable, non-mechanical switches
- Water-resistant or sealed enclosures in outdoor or wet environments
- Smart home wall switches and automation keypads
How to Use Capacitive Touch Switch HTTM Touch Button Sensor Module-
Mount the HTTM Touch Button module on the backside of a non-conductive surface (up to a few millimeters thick). Wire VCC to your 2.7 – 6 V supply, GND to ground, and route the OUT pin to a digital input on your microcontroller. When a finger approaches the panel, the OUT pin goes high (3.3 V), signalling a touch event.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage range does the HTTM module support?
The module operates on any 2.7 – 6 V DC supply. Its OUT pin switches to 3.3 V (± 0.1 V) when touched, making it compatible with most 3.3 V and 5 V microcontroller inputs.
Can I use this touch switch in a waterproof panel?
Yes. Since the HTTM module has no mechanical parts, you can mount it behind a thin non-conductive layer to create a sealed, moisture-resistant touch surface ideal for wet or outdoor environments.
What temperature range can this touch sensor handle?
The HTTM Touch Button Sensor Module reliably operates between 30 °C and 70 °C, ensuring stable performance in both room-temperature and warm industrial settings.
Technical Specifications
| Color | White |
|---|---|
| SKU | AI2958 |
| Weight | 0.00325 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Capacitive Touch Switch HTTM Touch Button Sensor Module- White is a versatile electronic switches/keypads modules used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
