1.09 Inch White 12864 OLED Module 7pin CH1115 Chip(Compatible SSD1306)

This is the White variant of the 1.09 Inch White 12864 OLED Module 7pin CH1115 Chip(Compatible SSD1306) in OLED Display, Display modules. Available at ₹325.68 (₹276.00 + GST) with free shipping across India.

Looking for Ch1115 Module? 1.09 Inch White 12864 OLED Module 7pin CH1115 Chip(Compatible SSD1306) is available at Zbotic with fast shipping across India.

1.09 Inch White 12864 OLED Module 7pin CH1115 Chip(Compatible SSD1306)

The 1.09-inch White 128×64 OLED Module with a 7-pin configuration and CH1115 chip (compatible with SSD1306) offers a compact yet vibrant display solution. With its 128×64 resolution, it delivers crisp, clear visuals, making it ideal for a variety of applications.

Powered by the CH1115 chip, which is compatible with SSD1306, this module ensures smooth integration with existing projects and libraries. Its white OLED display provides high contrast and excellent visibility, even in challenging lighting conditions.

The 7-pin design simplifies wiring, making it easy to connect with microcontrollers and other electronic devices. Whether used in portable gadgets, wearable tech, or embedded systems, this OLED module is a versatile and efficient display choice.

Features:

1. 128×64 Resolution: Provides crisp and clear visuals for displaying information and graphics.
2. White OLED Display: Offers high contrast and excellent visibility, suitable for various lighting conditions.
3. CH1115 Chip: Compatible with the SSD1306, ensuring seamless integration with existing projects and libraries.
4. 7-Pin Configuration: Simplifies connectivity, allowing for easy interfacing with microcontrollers and other electronic devices.
5. Compact Design: Ideal for applications where space is limited, such as portable gadgets, wearable devices, and embedded systems.
6. Versatile Usage: Suitable for a wide range of applications, including DIY projects, prototyping, and product development.
7. Low Power Consumption: Enables energy-efficient operation, making it suitable for battery-powered devices.
8. User-Friendly: Easy to use and integrate into electronic projects, making it accessible to hobbyists and professionals alike.

Specification:

1 X 1.09 Inch White 12864 OLED Module 7pin CH1115 Chip(Compatible SSD1306)

1.09 Inch White 12864 OLED Module 7pin CH1115 Chip Overview

The 1.09 Inch White 12864 OLED Module features a 128×64-pixel display driven by the CH1115 controller, offering crisp white-on-black graphics in a compact form factor. Designed for SPI communication, this module is ideal for embedding into microcontroller projects, wearables, and compact monitoring devices requiring clear status or graphical output.

Key Features of 1.09 Inch White 12864 OLED Module 7pin CH1115 Chip

• Resolution: 128×64 pixels for sharp text and simple graphics
• White OLED font on a black background for high contrast and wide viewing angles
• SPI interface with a 7-pin connection (VCC, GND, SCLK, MOSI, D/C, RST, CS)
• CH1115 driver chip compatible with SSD1306 libraries for easy integration
• Operating voltage: 3.3 V for low-power applications
• Compact display area (10.86 × 25.58 mm) and overall panel size (33 × 24 × 2.5 mm)
• Full-view PMOLED technology ensures uniform brightness across the panel
• Genuine product with fast shipping from Zbotic

Applications and Use Cases

• Wearable gadgets displaying steps, time, or notifications
• Embedded systems status screens on Arduino or ESP32 projects
• Battery monitors and power management panels
• DIY audio equipment showing VU meters or track information
• Portable medical devices for real-time parameter readouts
• Compact user interfaces in robotics or IoT sensor nodes

How to Use 1.09 Inch White 12864 OLED Module 7pin CH1115 Chip

To set up this OLED module, connect the 7 pins to your microcontroller’s SPI bus: 3.3 V to VCC, GND to ground, SCLK to SCK, MOSI to SDA/MOSI, plus D/C, RST, and CS lines. Install an SSD1306-compatible library and adjust the initialization parameters to use the CH1115 driver. Upload example code to verify communication and begin drawing text or graphics on the display.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

Is the CH1115 driver fully compatible with SSD1306 code?

Yes, the CH1115 chip shares the same command set as the SSD1306, allowing you to use most SSD1306 libraries with minimal changes in initialization.

Can I power this OLED module with 5 V?

No, this module is designed for 3.3 V operation. Supplying 5 V may damage the display. Use a level shifter or a 3.3 V regulator if your microcontroller runs at 5 V.

How do I adjust the contrast or brightness?

You can modify contrast settings via your SSD1306-compatible library’s initialization commands. Look for functions like setContrast() or displayDim() to fine-tune brightness.
