This is the Red variant of the 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin in Seven Segment Display. Available at ₹23.60 (₹20.00 + GST) with free shipping across India.
Looking for 0.56 Inch Red Display 0.56inch? 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin is available at Zbotic with fast shipping across India.
0.56 Inch Red Display 0.56inch – Description:
Introducing the 0.56-inch Red 2 Digit 7 Segment LED Display CC – 10Pin, a versatile component perfect for a variety of applications. This LED display provides outstanding clarity and reliability, making it an excellent choice for numerous electronic projects.
This LED display is perfect for displaying numerical data accurately and effectively in your DIY electronics projects. Whether you’re building a digital clock, a timer, or any other device that requires numeric display, this 7 segment LED display is the perfect choice.
Features:
- Bright Red LED chip ensures excellent visibility in any lighting conditions.
- Blackface design with Red LED segments for enhanced contrast and readability.
- Type: Common cathode, offering flexibility in circuit design.
- Equipped with 10 pins for seamless integration into your projects.
- Low current consumption for energy-efficient operation.
- High brightness for clear and vibrant display of numerical data.
- Easy to use with PCB mounting or on breadboard setups.
Specifications:
| Display Type | Seven segments |
|---|---|
| Configuration | Common Cathode |
| No. of Pins | 10 |
| LED colour | RED |
| No. of Digits | 2 Digits |
| Digit Height | 14mm |
| Operating current | 10mA |
| Wavelength | 640nm |
| Length (mm): | 25.20 |
| Width (mm): | 19 |
| Height (mm): | 8 |
| Weight (g): | 3 |
Package Includes:
- 1 x 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin
Attachments:
Datasheet
0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin Overview
The 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin is a compact numerical readout component featuring two digits of bright red segments on a black face. Designed as a common cathode module, it’s ideal for clear numeric indication in electronics projects like clocks, counters, and instrumentation panels.
Key Features of 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin
- Bright red AlGaAs-on-GaAs LED chips for vivid segment illumination
- 0.56-inch digit height offers excellent visibility in compact layouts
- Common cathode configuration simplifies ground referencing
- 10 pins including shared cathodes and individual segment connections
- Low current consumption for energy-efficient displays
- High brightness output ensures readability under various lighting
- Fast shipping across India from Zbotic’s nationwide warehouses
Applications and Use Cases
- DIY digital clocks and wall timers
- Electronic counters and frequency meters
- Voltage or temperature display modules in hobby projects
- Scoreboards for small games or quizzes
- Home automation panels showing numeric status codes
- Portable test instruments requiring simple numeric feedback
How to Use 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin
Begin by wiring the two common cathode pins to ground. Connect each of the remaining eight segment pins (A–G and DP) to your microcontroller or driver through suitable current-limiting resistors (typically between 150 Ω and 330 Ω). Drive segments with a LOW signal to illuminate, refreshing each digit in a multiplexed routine if both digits share the same segment lines.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How many pins does this display have and what are they for?
The module has 10 pins: two common cathode pins (one for each digit) and eight segment pins (seven segments plus decimal point). Each segment pin lights its corresponding bar when driven low.
What forward voltage and current are required?
Each red LED segment typically requires around 1.8–2.2 V forward voltage and can be driven at 10–20 mA. Always use a current-limiting resistor to protect the LEDs and ensure consistent brightness.
Can I multiplex both digits with a single microcontroller port?
Yes, by sharing the segment lines across both digits and alternately activating each common cathode, you can display different numbers on each digit using time-multiplexing at a refresh rate above 60 Hz to avoid flicker.
Technical Specifications
| Display Size | 0.56" |
|---|---|
| Pin Count | 10-pin |
| Color | Red |
| SKU | AI7226 |
| Weight | 0.0 kg |
| Availability | In Stock |
Applications & Use Cases
The 0.56 inch Red 2 Digit 7 Segment LED Display CC – 10Pin is a versatile seven segment display used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
