This is the 54mm variant of the XH2.54mm 7P Bend Pin Header Connector(Pack of 10) in FFC, FPC, Berg connectors. Available at ₹30.21 (₹25.60 + GST) with free shipping across India.
This is a 7Pin JST XH 2.54mm Pin Header Connector.
Elevate your electronic projects with our XH2.54mm 7P Bend Pin Header Connector pack, containing 10 units designed for reliable connections. These connectors are essential components for various applications, including PCB prototyping, breadboarding, DIY electronics projects, and more.
Features:
- Use of electrical fire retardant material.
- Solid and durable.
- Safe and easy to install.
- RoHS compliant.
Applications:
- AC power supply to PCs and lab equipment.
- Used in all types of RCs( cars, boats, planes).
- Also used in CCTV connections, pick-ups, etc
Upgrade your electronic projects with our XH2.54mm 7P Bend Pin Header Connector pack, providing reliable connections and versatility for your circuitry needs.
Specifications:
| Specification | Description |
|---|---|
| Pitch | XH2.54mm |
| Number of Pins | 7 |
| Connector Type | Bend Pin Header |
| Quantity | Pack of 10 |
Package Includes:
1 x 7Pin JST XH 2.54mm Pitch Header Connector (pack of 10)
XH2.54mm 7P Bend Pin Header Connector Overview
The XH2.54mm 7P Bend Pin Header Connector is a right-angle, 7-pin PCB header with 2.54 mm pitch, supplied in a pack of 10. It provides reliable, RoHS-compliant connections for PCB prototyping, power distribution, and custom wiring harnesses.
Key Features of XH2.54mm 7P Bend Pin Header Connector
- Pack of 10 genuine JST XH series right-angle headers
- 7-pin layout with standard 2.54 mm pitch for universal compatibility
- Bend-pin design for easy right-angle PCB mounting
- Electrical fire-retardant PBT housing for safety and durability
- RoHS compliant, solid solder-tail pins for secure connections
- Fast shipping from Zbotic – ships within 24 hours*
Applications and Use Cases
- Connecting ATX power leads to custom PCBs and lab power supplies
- Wiring harnesses in RC cars, boats, planes, and UAV controllers
- Power and signal distribution in CCTV camera systems
- Breadboard-to-PCB adapters for rapid prototyping
- Interfacing 3D printer control boards and filament sensors
- Custom audio or LED driver board connections
How to Use XH2.54mm 7P Bend Pin Header Connector
Align the bend pins with the matching 2.54 mm through-holes on your PCB footprint, insert the header until the housing rests flush, then solder each pin on the board’s underside. After soldering, snap on the corresponding JST XH 7-pin female housing to complete your wiring harness or power interface.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Which female housing mates with this connector?
This header is designed to pair with the standard 7-pole JST XH series female housing. Ensure you select the matching pitch (2.54 mm) XH-07 housing for a secure fit.
What PCB footprint is required for the bend-pin header?
The PCB footprint requires two parallel rows of 7 through-holes at 2.54 mm spacing, with hole diameters around 1 mm to accommodate the solder tails of the bend pins.
Can I solder this header with a standard reflow profile?
Yes. The electrical fire-retardant PBT housing and tinned brass pins withstand standard soldering temperatures. Avoid extended exposure above 260 °C to maintain housing integrity.
Technical Specifications
| Model | XH2 |
|---|---|
| Size | 54mm |
| Package Quantity | 10 pcs |
| SKU | AI4044 |
| Weight | 0.00455 kg |
| Availability | Out of Stock |
Applications & Use Cases
The XH2.54mm 7P Bend Pin Header Connector(Pack of 10) is a versatile ffc, fpc, berg connectors used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
