This is the 4V variant of the Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C 12S1P Lipo Smart Battery Pack With AS150U Plug in 5 Cell (18.5V) & 6 cell (22.2V ~ 25.2V) Lipo, Batteries, Chargers and Accessories, LiPo Battery. Available at ₹59,310.34 (₹50,263.00 + GST) with free shipping across India.
Looking for As150u Battery? Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C 12S1P Lipo Smart Battery Pack With AS150U Plug is available at Zbotic with fast shipping across India.
- Communication protocol CAN
- Communication protection
- Fuel gauge.
- Self-inspection
- Using time log
- Current detection
- Ultra-Low power consumption
- Abnormal log
| Minimum Capacity | 16000mAh / 16Ah |
| Configuration | 12S1P / 44.4V / 12 Cells |
| Discharge Rate | 15C |
| Max Burst Discharge Rate | 30C |
| Net Weight(±20g) | 4700g |
| Dimensions | 224x163x90mm (L x W x H) |
| Charge Plug | Micro USB+JST-XHR |
| Wire Gauge | 8# |
| Discharge Wire Length(mm) | 230mm |
| Connector Type | AS150U |
Package Include-
1 X Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C 12S1P Lipo Smart Battery Pack With AS150U Plug
Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C Overview
The Original Tattu Plus 1.0 Compact Version is a 16000mAh, 12S1P 44.4V LiPo smart battery pack with an AS150U plug, designed for high-performance drones and industrial UAV applications. It delivers reliable power and on-board intelligence for extended flight operations in mapping, inspection, agriculture and more.
Key Features of Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C
- High Capacity: 16000mAh cells provide extended runtime for professional UAVs
- Stable Output: 12S1P configuration at 44.4V with 15C continuous and 30C burst discharge
- Smart Management: Integrated data acquisition, automatic cell equalization and power calculation
- Safety Alerts: Built-in discharge anti-sparking, charging warning and abnormal state alarms
- CAN Interface: Standard CAN communication protocol for real-time monitoring and control
- Secure Connection: AS150U discharge plug ensures sturdy and low-resistance link
- Fast Shipping: Genuine Tattu battery dispatched quickly across India from Zbotic
Applications and Use Cases
- Aerial cinematography with Freefly and AltaX drones
- Precision agricultural spraying UAVs
- Security surveillance and mapping drone missions
- Power grid inspection and infrastructure monitoring
- Industrial surveying and remote inspection operations
How to Use Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C
Connect the Tattu Plus 1.0 battery to your UAV via the AS150U plug, ensuring correct polarity and a secure fit. Use a compatible 12S LiPo charger with charging butler support, set the charge current to 1C or below, and monitor the process via the smart battery’s CAN interface for voltage, temperature and state-of-charge data before each flight.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I use this battery with any 12S drone platform?
This Tattu Plus 1.0 pack is compatible with any UAV platform designed for 12S (44.4V) LiPo batteries and AS150U discharge connectors. Always verify your frame’s maximum voltage rating and plug type before installation.
Which charger is recommended for charging the 16000mAh pack?
Use a professional 12S LiPo charger that supports the charging butler function and a maximum charge voltage of 50.4V. Set the charge current to 1C (16A) or below to maintain cell health and ensure safe charging.
How long will the battery last during flight?
Flight time depends on your UAV’s weight, payload and throttle usage. On a medium-weight multirotor under moderate load, expect 20–30 minutes of operation per full charge.
Portable Power Station Build: 500Wh Battery Pack
Building a portable power station with 500Wh capacity gives you a versatile, rechargeable power source for camping, outdoor...
Read More →
USB-C PD Trigger: Get 5V-20V from Any USB-C Charger
Table of ContentsWhat Is USB Power Delivery How PD Trigger Boards Work Requesting 9V, 12V, and 20V QC...
Read More →
Hand Crank Generator: Emergency USB Power Source
Table of ContentsDC Motor as Generator Gear Ratio Design Voltage Regulation Circuit USB Output Integration Mechanical Design Considerations...
Read More →Technical Specifications
| Brand | Tattu |
|---|---|
| Model | AS150U |
| Operating Voltage | 44.4V |
| Battery Capacity | 16000mAh |
| Discharge Rate | 15C |
| SKU | AI5402 |
| Weight | 5.665 kg |
| Availability | In Stock |
Applications & Use Cases
The Original Tattu Plus 1.0 Compact Version 16000mAh 44.4V 15C 12S1P Lipo Smart Battery Pack With AS150U Plug is a versatile 5 cell (18.5v) & 6 cell (22.2v ~ 25.2v) lipo used across a wide range of applications including FPV drones, RC vehicles, portable electronics, robotics, and airsoft guns.
Common use cases:
- Powering an FPV racing drone
- Running a high-current RC car
- Portable power for field robotics
This product is ideal for drone pilots, RC enthusiasts, and robotics builders.
Technical Tip: Never discharge below 3.5V per cell. Store at 3.8V per cell. Always use a balance charger and never leave charging unattended. Use a LiPo bag for safety.
