Looking for 75a Motor? T Motor AT 75A 6S is available at Zbotic with fast shipping across India.
T Motor AT 75A 6S is compatible with various flight-control systems and supports a signal frequency of up to 621 Hz at a. It has a special core program for multi-rotor controllers that greatly improves throttle response and specially optimized software for excellent compatibility with disc-type motors. The twisted-pair design of the throttle signal cable effectively reduces the crosstalk produced in signal transmission and makes flight more stable. All settings except the timing are preset, making usage simple, highly intelligent and adaptive.
Features:
- Multiple protection features: Low-voltage cut-off protection / over-heat protection / throttle signal loss protection.
- 3 start modes: Normal / Soft / Super-Soft, compatible with fixed-wing aircraft and helicopters.
- Throttle range can be configured and is fully compatible with all transmitters currently available on market.
- Smooth, linear and precise throttle response.
- Our pocket-sized Program Card can be purchased separately for extremely easily programming the ESC at the field.
- With a program card, you can activate the music playing function of the ESC, and totally there are 15 songs that can be selected
Package Includes:
1 x T Motor AT 75A 6S
T Motor AT 75A 6S Overview
The T Motor AT 75A 6S is a high-performance electronic speed controller (ESC) designed for 6S LiPo-powered multirotor drones and racing quads. It delivers a continuous current of 75 A with bursts up to 95 A, integrating a switch-mode BEC outputting 5 V/5 A for reliable onboard power.
Key Features of T Motor AT 75A 6S
- Continuous current rating of 75 A with 95 A burst capacity for demanding flight maneuvers
- Switch-mode BEC providing stable 5 V/5 A output to power flight controllers and receivers
- Compatible with multiple flight-control systems; supports signal frequencies up to 621 Hz
- Optimized core firmware for improved throttle response and disc-motor compatibility
- Twisted-pair throttle signal cable reduces crosstalk for smoother, more stable flight
- Comprehensive protection: low-voltage cut-off, over-heat shutdown, and throttle signal loss safeguard
- All settings factory-preset except motor timing for plug-and-play installation
- Fast shipping from Zbotic across India
Applications and Use Cases
- 6S racing quadcopters requiring rapid throttle response and high current capacity
- Cinematography drones carrying cameras and gimbals, powered by on-board BEC
- Heavy-lift agricultural or inspection multirotors needing over-current protection
- Long-range FPV platforms that demand signal stability and efficient power delivery
- Industrial survey drones operating in varied environments with thermal protection
- Custom DIY drone builds where a reliable 75 A ESC ensures consistent performance
How to Use T Motor AT 75A 6S
Install the AT 75A 6S by soldering the three motor phase wires and 6S LiPo battery leads to the ESC pads, then connect the 3-wire twisted-pair signal cable to your flight controller’s throttle input. Power up the system, follow your flight controller’s ESC calibration procedure, and confirm the BEC output is delivering 5 V/5 A to the receiver. The ESC’s preset settings streamline setup—only motor timing adjustment is optional for fine-tuning.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What battery configuration is required for the T Motor AT 75A 6S?
This ESC is designed for 6S LiPo batteries (22.2 V nominal). Ensure your battery cables are properly soldered and that your pack can deliver sufficient current to support up to 95 A bursts.
How do I calibrate the throttle range on the AT 75A 6S?
Power on your transmitter at full throttle, then connect the battery to the ESC. Wait for the tone sequence, move the throttle to zero, and listen for confirmation beeps. Finally, verify motor spin responds linearly from idle to full throttle.
What safety protections are built into this ESC?
The AT 75A 6S features low-voltage cut-off to prevent battery damage, over-heat shutdown to avoid thermal stress, and throttle signal loss protection to ensure motors stop if the control link is interrupted.
FPV Goggles Buying Guide India: Analog vs Digital
Table of Contents Understanding FPV Goggles Buying Guide India Key Components and Requirements Step-by-Step Setup Guide Configuration and...
Read More →
Drone Delivery System: Payload Release Mechanism
Table of Contents Understanding Drone Delivery System Key Components and Requirements Step-by-Step Setup Guide Configuration and Optimisation Practical...
Read More →
GPS Return to Home: Setup on Betaflight and iNav
Table of Contents Understanding GPS Return to Home Key Components and Requirements Step-by-Step Setup Guide Configuration and Optimisation...
Read More →Technical Specifications
| Current Rating | 75A |
|---|---|
| Cell Configuration | 6S |
| SKU | AI1635 |
| Weight | 0.117 kg |
| Availability | In Stock |
Applications & Use Cases
The T Motor AT 75A 6S is a versatile (esc) drone speed controller used across a wide range of applications including brushless motor speed control, FPV drone builds, multirotor platforms, and RC aircraft.
Common use cases:
- Controlling motor speed in a quadcopter
- Replacing a burnt ESC after a short
- Upgrading to BLHeli_32 for smoother throttle response
This product is ideal for drone builders and RC enthusiasts.
Technical Tip: Choose ESC amperage 20% above your motor's max draw. DShot600 protocol recommended for modern builds.
