STM32F103CBT6 Maple Mini
Description:
Unlock the potential of ARM microcontroller development with our STM32F103CBT6 Maple Mini board. This low-cost minimum system development board is perfect for learners eager to delve into the intricacies of STM32 microcontrollers featuring the ARM Cortex-M3 32-bit core.
Features:
- Brand new and high-quality STM32 board
- Operates at a frequency of 72MHz
- Offers 128KB flash memory and 20KB SRAM
- Provides 34 digital I/O pins (GPIOs) for versatile connectivity
- Includes 12 PWM pins at 16-bit resolution for precise control
- Equipped with 9 analog input (ADC) pins at 12-bit resolution
- Features 2 SPI peripherals and 2 I2C peripherals for enhanced functionality
Specifications:
- Model: STM32F103CBT6
- Core: ARM 32 Cortex-M3 CPU
- Power and I/O voltage range: 2.0-3.6V
Whether you’re a novice learner or a seasoned developer, the STM32F103CBT6 Maple Mini board offers a comprehensive platform for exploring and mastering ARM microcontroller development. Experience high-quality performance and reliable operation with our STM32 board.
Specifications:
| Feature | Specification |
|---|---|
| Model | STM32F103CBT6 |
| Core | ARM Cortex-M3 CPU |
| Operating Frequency | 72MHz |
| Flash Memory | 128KB |
| SRAM | 20KB |
| Digital I/O Pins (GPIOs) | 34 |
| PWM Pins | 12 (16-bit resolution) |
| Analog Input (ADC) Pins | 9 (12-bit resolution) |
| SPI Peripherals | 2 |
| I2C Peripherals | 2 |
| Power & I/O Voltage Range | 2.0-3.6V |
Datasheet:
Package Includes :
1 xSTM32F103CBT6 Maple Mini ARM
STM32F103CBT6 Maple Mini Overview
The STM32F103CBT6 Maple Mini is a compact development board built around the ARM Cortex-M3 32-bit core running at 72 MHz. Designed for embedded system enthusiasts and learners, it provides a minimum system platform with ample memory and I/O to prototype a wide range of microcontroller projects.
Key Features of STM32F103CBT6 Maple Mini
- ARM 32-bit Cortex-M3 CPU clocked at 72 MHz for responsive performance
- 128 KB onboard flash memory and 20 KB SRAM for code and data storage
- 34 digital GPIO pins plus 12 PWM channels (16-bit resolution) and 9 ADC inputs (12-bit resolution)
- Two SPI ports and two I²C ports for flexible peripheral connectivity
- Wide operating voltage range of 2.0 – 3.6 V to suit various power sources
- Fast shipping from Zbotic and 100% genuine STM32F103CBT6 chip
Applications and Use Cases
- Prototyping motor control and robotics projects using PWM outputs
- Real-time data acquisition and logging with on-board ADC channels
- Interfacing sensors and displays via SPI and I²C communication
- Developing custom power management or battery monitoring units
- Educational firmware development and hands-on STM32 learning platform
How to Use STM32F103CBT6 Maple Mini
Begin by powering the board within its 2.0 – 3.6 V range, then connect a programmer such as ST-Link or a USB-to-serial adapter if using a bootloader. Install STM32CubeIDE or Maple IDE on your computer, select the STM32F103CBT6 target, write your firmware in C/C++ and upload via the chosen interface. Use the rich GPIO, PWM, ADC, SPI and I²C pins to connect sensors and actuators as needed.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the operating voltage range for the STM32F103CBT6 Maple Mini?
The board operates between 2.0 V and 3.6 V. Ensure your power supply stays within this range to maintain stable operation and prevent damage.
How many analog inputs can I use on this board?
The Maple Mini provides 9 analog input pins (ADC) at 12-bit resolution, allowing you to connect a variety of analog sensors and read precise voltage levels.
Which interfaces are available for peripheral communication?
This development board includes two SPI ports and two I²C ports, offering straightforward connections to displays, sensors, memory devices, and other modules.
Technical Specifications
| Model | STM32F103CBT6 |
|---|---|
| SKU | AI2196 |
| Weight | 0.01007 kg |
| Availability | Out of Stock |
Applications & Use Cases
The STM32F103CBT6 Maple Mini is a versatile arm microcontroller used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
