Features:
- 5V single power supply
- Pin set up four kinds of pure sine wave output frequency: fixed frequency 50 hz pure sine wave; 60 hz fixed frequency pure sine wave; 0-100 hz pure sine wave frequency is adjustable; 0-400 hz pure sine wave frequency is adjustable.
- Unipolar and bipolar modulation
- Comes with dead band control, pin set up 4 dead time: 300nS dead time; 500nS dead time ; 1.0uS dead time ; 1.5uS dead time
- External 12MHz crystal oscillator
- PWM carrier frequency 23.4KHz
- Voltage, current, real time temperature feedback
- Overvoltage, undervoltage, overcurrent and overheating protection
- Soft-start mode pin setting the response time of 1S
- Serial communication to set the output voltage, frequency and other parameters External
- External serial port 128 * 32 LCD module 1602 display the voltage, frequency, temperature and electric current of the inverter and other information;
Applications:
- Single phase pure sine wave inverter
- PV Inverter
- Wind power inverter
- Uninterruptible Power Supply UPS System
- Digital generator system
- IF power
- Single-phase motor speed controller
- Single-phase inverter
- Sine wave dimmer
- Sine wave regulator
- Sine wave generator
LCD description:
PCB & Stencil Ordering Instructions
Instructions for PCB Orders 1. Solder-Resistance Bridges For solder-resistance bridges, spacing between pads/pins requires at least 0.2mm on...
Read More →
Arduino Pulse Oximeter MAX30102: Heart Rate and SpO2
Table of ContentsIntroductionComponents and Hardware SetupWiring Diagram and ConnectionsComplete Code with ExplanationCustomization and ImprovementsTroubleshooting Common IssuesAdvanced Features and...
Read More →
Arduino Keyboard HID: Simulate Typing with ATmega32U4
What if your Arduino could pretend to be a keyboard? Not just send serial data — but actually...
Read More →Technical Specifications
| Model | EGS002 |
|---|---|
| SKU | AI4198 |
| Weight | 0.02 kg |
| Availability | Out of Stock |
