Product Description
- The MAX30100 is an integrated pulse oximeter and heart rate monitor sensor solution. This optical sensor uses two LEDs—one red and one infrared—to emit light at different wavelengths and measures the absorbance of pulsing blood through a photodetector.
- This specific LED combination is optimized for accurate readings from the tip of a finger. It is fully configurable via software registers, and digital output data is stored in a 16-deep FIFO within the device. Communication with a host microcontroller is facilitated through an I2C digital interface.
- The pulse oximetry subsystem includes ambient light cancellation (ALC), a 16-bit sigma-delta ADC, and a proprietary discrete-time filter.
- Designed for ultra-low power consumption, the MAX30100 is ideal for battery-operated systems, operating on a supply voltage range of 1.8 to 3.3V. It is suitable for use in wearable devices, fitness trackers, and medical monitoring equipment.
- Additionally, the MAX30100 can be powered down via software, maintaining negligible standby current while keeping the power supply connected at all times.
- VIN Input voltage (1.8V to 5.5V)
- SCL IIC-SCL
- SDA IIC-SDA
- INT MAX30100INT
- IRD MAX30100 IR_DRV
- RD MAX30100 R_DRV
- GND Ground
Features:
- It is an integrated pulse oximetry and heart rate monitor sensor solution.
- Integrated LEDs, Photo Sensor, and High-Performance Analog Front -End
- Complete Pulse Oximeter and Heart-Rate Sensor Solution Simplifies Design
- Measures absorbance of pulsing blood
- I2C interface plus INT pin
- Tiny 5.6mm x 2.8mm x 1.2mm 14-Pin Optically Enhanced System-in-Package
- Ultra-Low-Power Operation Increases Battery Life for Wearable Devices
- Programmable Sample Rate and LED Current for Power Savings
- Ultra-Low Shutdown Current (0.7µA, typ)
- Advanced Functionality Improves Measurement Performance
- High SNR Provides Robust Motion Artifact Resilience
- Integrated Ambient Light Cancellation
- High Sample Rate Capability
- Fast Data Output Capability
Applications
- Fitness Assistant Devices
- Medical Monitoring Devices
- Wearable Devices
Specification:
- Optical sensor: IR and red LED combined with a photodetector
- Measures absorbance of pulsing blood
- I2C interface plus INT pin
- 3.3V power supply complete pulse oximeter and heart rate sensor solution, simplifies design, integrated LEDs, photo sensor, and
- high-performance analog front
- Ultra low power operation increases battery life for wearable devices
- Advanced functionality improves measurement performance, high SNR provides robust motion artifact resilience integrated
- ambient, light cancellation high sample rate capability fast data output capability
- It is an integrated pulse oximetry and heart rate monitor sensor solution.
| Color | Green |
|---|---|
| Length (mm): | 19 |
| Width (mm): | 14.5 |
| Height (mm): | 3 |
| Weight (g): | 2 |
Package Includes
- 1 x MAX30100 Pulse Oximeter Heart Rate Sensor Module
