Looking for Kp Original 523450 Battery? KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable LiPo Battery is available at Zbotic with fast shipping across India.
Description:
Introducing the 523450 1000mAh 3.7Vsingle cell Rechargeable LiPo Battery, designed for compact electronic devices requiring reliable power in a small form factor. With its high energy density and lightweight design, this battery is ideal for applications in drones, remote controls, wearables, and other portable electronics.
Features:
- Overcharge Protection: Yes
- Over-discharge Protection: Yes
- Short Circuit Protection: Yes
- Fire Resistance: Designed with protective features to minimize risk.
Specifications:
- Model Number: 523450
- Type: Lithium Polymer (LiPo)
- Configuration: Single Cell
- Nominal Voltage: 3.7V
- Capacity: 1000 mAh
- Discharge Rate: 1C (1000 mA continuous current)
- Charge Voltage: 4.2V (maximum)
- Discharge Cut-off Voltage: 3.0V (minimum)
- Dimensions: 52 x34 x5.0 mm (L.B.H)
- Weight: Approximately 40g (may vary slightly by manufacturer)
- Temperature Range for Charging: 0°C to 45°C
- Temperature Range for Discharging: -20°C to 60°C
- Cycle Life: Approximately 300-500 cycles at standard charge/discharge rates
- Self-Discharge Rate: Approximately 3-5% per month
- Charging Method: Constant current / constant voltage (CC/CV)
- Recommended Charge Current: 0.5C to 1C (500 mA – 1000 mA)
- Charge Time: Approximately 1 to 2 hours, depending on charge current.
Applications:
- Remote control devices
- Drones and UAVs
- Mobile devices and electronics
- Wearable technology
- Portable power solutions
Package includes:
- 1 x KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable LiPo Battery
KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable Overview
The KP Original 523450 is a single-cell 3.7V 1000mAh rechargeable LiPo battery designed for compact electronic devices. With a slim 52×34×5 mm profile and a 1C discharge rate, it delivers reliable, lightweight power for drones, remote controls, wearables and other portable gadgets.
Key Features of KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable
- High Energy Density: 1000 mAh in a 52×34×5 mm form factor for extended runtime without bulk
- 1C Discharge Rate: Continuous 1000 mA output suitable for low- to moderate-current applications
- Built-In Protections: Overcharge, over-discharge and short-circuit safeguards for safe operation
- Fire Resistant Design: Reinforced cell construction to minimize risk under fault conditions
- Lightweight Construction: Ideal for weight-sensitive platforms like micro drones and wearable electronics
- Fast Shipping from Zbotic: Genuine KP Original units dispatched across India within 24 hours
Applications and Use Cases
- Micro drones and FPV quadcopters requiring compact, reliable power
- Handheld remote controls for cars, boats and model aircraft
- Wearable devices such as fitness trackers or smart patches
- DIY electronics projects and custom PCB power supplies
- Battery backups for low-power IoT sensors and data loggers
- Portable audio recorders and mini lighting rigs
How to Use KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable
Connect the battery leads to your device’s matching polarity terminals and secure it in a well-ventilated compartment. Charge using a LiPo-compatible charger set to 4.2 V maximum and a charge current at or below 1 A. Monitor the battery during charging and discharging, and avoid exposing it to extreme heat or puncture.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum continuous discharge current of this LiPo battery?
The KP Original 523450 is rated at a 1C discharge rate, meaning it can deliver up to 1000 mA continuously without overheating or voltage sag, making it suitable for moderate-load applications.
Does the KP Original 523450 have built-in protection circuitry?
Yes, this single-cell LiPo includes integrated overcharge, over-discharge and short-circuit protection to safeguard both the battery and your device under normal operating conditions.
How should I charge and store this LiPo battery?
Use a dedicated LiPo charger set to a maximum charge voltage of 4.2 V and a charge current at or below 1 A. For long-term storage, charge to approximately 3.8 V per cell, keep the battery in a cool, dry place, and avoid full discharge.
3.3V Power Supply: LDO and Buck Options for ESP32
Table of ContentsWhy 3.3V Matters AMS1117-3.3 LDO Regulator Buck Converter for 3.3V Voltage Level Shifting Noise Considerations for...
Read More →
12V Power Supply Selection: Adapters and Batteries
Table of Contents12V Adapter Types SMPS Power Supplies Battery-Based 12V Sources Current Rating Selection Guide Connector Types in...
Read More →
LiFePO4 Battery: Advantages, Cycle Life & Buying Guide India
When it comes to selecting a lithium battery for solar storage, electric vehicles, or long-term DIY power systems,...
Read More →Technical Specifications
| Brand | KP |
|---|---|
| Battery Capacity | 1000mAh |
| Interface / Protocol | BLE |
| SKU | AI6768 |
| Weight | 0.03 kg |
| Availability | Out of Stock |
Applications & Use Cases
The KP Original 523450 1000mAh 3.7Vsingle cell Rechargeable LiPo Battery is a versatile single cell micro lipo battery used across a wide range of applications including FPV drones, RC vehicles, portable electronics, robotics, and airsoft guns.
Common use cases:
- Powering an FPV racing drone
- Running a high-current RC car
- Portable power for field robotics
This product is ideal for drone pilots, RC enthusiasts, and robotics builders.
Technical Tip: Never discharge below 3.5V per cell. Store at 3.8V per cell. Always use a balance charger and never leave charging unattended. Use a LiPo bag for safety.
