Looking for Frsky R9 Stab Receiver? Frsky R9 stab OTA Receiver is available at Zbotic with fast shipping across India.
FrSky R9 STAB OTA telemetry receiver.It is a 900MHz/868MHz long-range and stabilization receiver with a built-in 3-axis gyroscope and 3-axis accelerometer. In order to fully enjoy the benefits of this system, please read the instruction manual carefully.
R9 STAB OTA has 8 PWM channels, on traditional fixed-wing models it will support stabilization, automatic level, hover and knife-edge flight modes. For delta wings and V-tail models, it supports stabilization and automatic level flight modes.
R9 STAB OTA receiver implements the ACCESS protocol and brings the user improved performance and features. It supports wireless over-the-air firmware updates, making binding to receivers even easier as well as conveniently checking the current receiver firmware version.
Features:
- ACCESS protocol and supports OTA functions
- 900MHz/868MHz long-range with low latency
- Built-in 3-axis gyroscope and 3-axis accelerometer
- Support S.Port
- Supports quick configuration for setting multiple flight modes (quick mode)
- Detachable Ipex1 connector antenna
- Low Battery voltage detection supported
- Multiple configuration methods (LUA script and FreeLink)
Specifications:
- Model: R9 STAB OTA
- Numbers of Channel: 8/16CH (CH16 outputs RSSI)
- Operating Voltage: DC 3.5V~10V
- Operating Current: [email protected]
- Measuring range of gyroscope: ±2000dps
- Measuring range of acceleration: ±4g
- Compatibility: R9M Lite/R9M/R9M 2019 with ACCST firmware
- R9M Lite/R9M Lite Pro/R9M 2019 with ACCESS firmware
- Dimension: 45.7 x 26.3 x 16.2mm
- Weight: 18.6g
Packages Includes:
1 x Frsky R9 stab OTA Receiver
1 x Instructions Manual
Frsky R9 stab OTA Receiver Overview
The Frsky R9 STAB OTA Receiver is a long-range 900MHz/868MHz telemetry RX featuring a built-in 3-axis gyroscope (±2000dps) and 3-axis accelerometer (±4g) for onboard stabilization. It employs the ACCESS protocol and supports wireless over-the-air firmware updates to unlock advanced flight modes on fixed-wing and delta-wing models.
Key Features of Frsky R9 stab OTA Receiver
- ACCESS protocol for robust 900/868MHz long-range control and telemetry
- Integrated 3-axis gyroscope and accelerometer for auto level, hover and knife-edge modes
- 8 PWM outputs with CH16 dedicated RSSI channel for seamless servo and telemetry integration
- Wireless OTA firmware updates—no disassembly required
- Wide input range DC 3.5–10V with low 140mA current draw at 7.4V
- Fast shipping across India from Zbotic
Applications and Use Cases
- Fixed-wing RC airplanes needing automatic level, hover and knife-edge stabilization
- Delta wing and V-tail models utilizing auto level and stabilization modes
- Long-range FPV flights with real-time RSSI telemetry
- Autonomous UAVs requiring onboard motion sensing and stabilization
- Gliders and sailplanes for extended-range signal monitoring
How to Use Frsky R9 stab OTA Receiver
Connect a 3.5–10V BEC power source to the receiver, press and hold the bind button while powering up to bind with your ACCESS transmitter, then plug servos into the PWM ports. Configure stabilization modes and calibrate the gyroscope/accelerometer via your transmitter’s flight mode menu. For firmware updates, enter OTA mode on the receiver and initiate the update from the transmitter’s firmware menu.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How many channels does the R9 STAB OTA Receiver support?
The receiver offers 8 PWM channels for servos and a dedicated 16th channel to output RSSI telemetry, making it ideal for both control and signal monitoring.
Which flight modes are available on this receiver?
Fixed-wing setups can use stabilization, automatic level, hover and knife-edge modes, while delta wing and V-tail models support stabilization and automatic level only.
How do I perform an OTA firmware update?
Place the receiver in OTA bind mode by holding its bind button at power-up, then use your ACCESS transmitter’s firmware update function to upload the latest firmware wirelessly.
