ESP8266 Serial Port To Wi-Fi Module, FL-M1S

This ESP8266 Serial Port To Wi-Fi Module, FL-M1S  serial transceiver module, based on ESP8266 SoC with an integrated TCP/IP protocol stack It can either host the application or offload all Wi-Fi networking functions from another application processor.

ESP8266 has powerful onboard processing and storage capabilities allowing it to integrate with sensors and other devices through GPIOs with minimal development up-front and minimal loading during runtime.

Its high degree of on-chip integration allows for minimal external circuitry, and the entire solution, including the front-end module, is designed to occupy minimal PCB area.

Add Wi-Fi connectivity to your projects quickly, easily and painlessly! The ESP8266 is a highly integrated chip designed for the needs of any IoT project. It offers a complete and self-contained Wi-Fi networking solution. Allowing it to either host a small application or to offload all Wi-Fi networking functions from another MCU.

This module is a WiFi serial transceiver module, based on ESP8266 SoC with an integrated TCP/IP protocol stack. As a TTL ‘Serial to Wireless Internet’ device, this module easily interfaces with typical microcontrollers (MCU) to communicate via TTL serial to instantly add Wi-Fi connectivity. It runs off 3.3V, and can draw almost 500mA of current for up to a really impressive +19.5dBm output power in 802.11b mode! That gives this module a range over a hundred meters!

ESP8266 has powerful onboard processing and storage capabilities that allow it to be integrated with the sensors and other application specific devices through its GPIOs with minimal development up-front and minimal loading during run-time. Its high degree of on-chip integration allows for minimal external circuitry.

Features :

1. SDIO 2.0, SPI, UART
2. Integrated RF switch, balun, 24dBm PA, DCXO, and PMU
3. It equips integrated RISC processor, on-chip memory and external memory interfaces
4. Featuring integrated MAC/baseband processors
5. I2S interface for high fidelity audio applications
6. On-chip low-dropout linear regulators for all internal supplies
7. Integrated WEP, TKIP, AES, and WAPI engines
8. Wi-Fi Direct (P2P), soft-AP
9. Integrated TCP/IP protocol stack
10. Integrated TR switch, balun, LNA, power amplifier and matching network
11. Integrated PLL, regulators, DCXO and power management units
12. Power down leakage current of <10uA
13. Integrated low power 32-bit CPU could be used as an application processor
14. SDIO 1.1/2.0, SPI, UART
15. STBC, 1×1 MIMO, 2×1 MIMO
16. A-MPDU & A-MSDU aggregation & 0.4ms guard interval
17. Wake up and transmit packets in < 2ms
18. Standby power consumption of < 1.0mW (DTIM3)

Package Includes :

1 x ESP8266 Serial Port To Wi-Fi Module, FL-M1S

Tutorial :

ESP8266 ARDUINO TUTORIAL

About Esp8266 Serial Port To Wi-fi Module

ESP8266 Serial Port To Wi-Fi Module, FL-M1S is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Generic, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.

Product Details

• Brand: Generic
• SKU: AI1350
• Category: Other ESP WIFI Modules

Why Buy from Zbotic?

Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Esp8266 Serial Port To Wi-fi Module and other products.

Applications

Esp8266 Serial Port To Wi-fi Module can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Esp8266 Serial Port To Wi-fi Module today and start building.

ESP8266 Serial Port To Wi-Fi Module, FL-M1S Overview

The ESP8266 Serial Port To Wi-Fi Module, FL-M1S is a compact wireless transceiver based on the ESP8266 SoC. It provides a fully integrated TCP/IP stack and high-power Wi-Fi connectivity, enabling you to add Wi-Fi networking to microcontroller projects via a simple UART interface.

Key Features of ESP8266 Serial Port To Wi-Fi Module, FL-M1S

• Supports 802.11 b/g/n standards with Wi-Fi Direct (P2P) and soft-AP modes
• Built-in TCP/IP protocol stack for standalone or host-offload operation
• Integrated RF front-end: TR switch, balun, LNA, power amplifier and matching network
• High output power: up to +19.5 dBm in 802.11b mode for extended range
• Ultra-low power down leakage current <10 µA for battery-powered designs
• On-chip 32-bit CPU, PLL, regulators, DCXO and power management units reduce external components
• Genuine product with fast shipping directly from Zbotic’s warehouse

Applications and Use Cases

• Logging sensor data remotely via UART to cloud services
• Home automation: control relays, lights and appliances over Wi-Fi
• Wireless serial bridging for legacy RS-232/TTL devices
• DIY IoT gadgets: smart thermostats, security cameras and environmental monitors
• Industrial telemetry: send machine metrics to dashboards in real time
• Prototyping Wi-Fi enabled wearables and portable electronics

How to Use ESP8266 Serial Port To Wi-Fi Module, FL-M1S

Connect the module’s VCC and GND to a 3.3 V supply, then wire the TX/RX pins to your MCU’s UART lines. Configure the baud rate (default 115200 bps) and use AT commands or custom firmware to join an access point or create a soft-AP. Power-down control and GPIO pins allow you to manage low-power modes and interface with sensors or actuators directly.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

What voltage does the FL-M1S module require?

The ESP8266 FL-M1S module operates at 3.3 V. Ensure you use a stable regulator capable of supplying at least 300 mA peak during Wi-Fi transmissions.

Can I run custom firmware on the FL-M1S?

Yes. Although it ships with AT command firmware, you can flash NodeMCU, Arduino, MicroPython or other ESP8266-compatible firmware via the UART bootloader pins.

How do I reduce power consumption in battery projects?

Use the module’s power-down pin (CH_PD) and deep-sleep AT commands. Deep-sleep mode reduces leakage current below 10 µA, ideal for intermittent data-logging applications.
