Cat_4_Mini_HS1278
Description:
The Foxeer Cat 4 Mini FPV Camera delivers an unparalleled FPV racing experience. Its compact size doesn’t compromise on performance, allowing you to capture clear and immersive footage. With its exceptional image quality and wide dynamic range, you’ll never miss a moment of the action. Designed for durability, this camera is built to withstand the rigors of high-speed racing. Featuring low latency and a wide voltage range, it ensures a seamless and reliable FPV feed. The adjustable camera tilt and versatile mounting options make it easy to customize to your preferences. Get ready to elevate your FPV game with the Foxeer Cat 4 Mini FPV Camera.
Specification:
| Item Type: | FPV Camera |
| Resolution (TVL): | 1200 |
| Color | Black |
| Sensor Type | Sony 1/3″ CMOS Sensor |
| Scale | 4:3(Default)/16:9 Switchable |
| TV System | PAL(Default)/NTSC Switchable |
| Lens | M12 2.1mm Low Light Lens |
| Field of View (FOV): | 4:3 FOV-H: 100° FOV-D:125° 16:9 FOV-H: 100° FOV-D:115° |
| Shutter Speed | PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec |
| Video Output | CVBS Analog Signal |
| Minimum Illumination | 0.00001Lux |
| White Balance | Auto |
| DNR | 3DNR |
| WDR | 100dB |
| Day/Night | EXT/Auto/Color/B&W |
| Flight OSD | Voltage/Cam Title/Time |
| Input Voltage (V): | 4.6V~20V |
| Language | ENGLISH /中文/ PYCCKNN / ESPANOL / ITALIANO /FRANCAIS/POLSKIM/ PORTUGUES / 日本语 / EAAHNIKA |
| Operating Temperature (°C): | -10°~50°C RH90% MAX |
| Operating humidity | 20~80% |
| Storage Temperature (°C): | -20°~70°C |
| Consumption | 95mA±15% @ DC12V |
| Overall Dimension | 22*22mm |
Features:
- Less Noise
- Low Latency
- 0.00001LUX Super Starlight
- Exclusive optimization for LED
- Switchable 4:3/16:9 & PAL/NTSC
- Large Aperture Night Vision Lens
- Supports OSD & Menu Remote Control with Foxeer FC
Package Includes:
1x Foxeer Cat 4 Mini FPV Camera 1x Bracket 1x OSD Board 1x 2-Pin OSD Cable 1x Servo Cable 12 x Bracket Screws 6 x Gasket Ring
Technical Specifications
| Brand | Foxeer |
|---|---|
| SKU | AI8208 |
| Weight | 0.051 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Cat_4_Mini_HS1278 is a versatile fpv cameras used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
