This is the 5V variant of the Adafruit PRO Trinket – 5V 16MHz in Boards Compatible with Arduino. Available at ₹831.90 (₹705.00 + GST) with free shipping across India.
Looking for Adafruit Pro Trinket –? Adafruit PRO Trinket – 5V 16MHz is available at Zbotic with fast shipping across India.
The trinket may be small, but do not be fooled by its size! It’s a tiny microcontroller board, built around the Atmel ATtiny85, a little chip with a lot of power. We wanted to design a microcontroller board that was small enough to fit into any project, and low cost enough to use without hesitation. Perfect for when you don’t want to give up your expensive dev-board and you aren’t willing to take apart the project you worked so hard to design. It’s our lowest-cost Arduino-IDE programmable board!
The Attiny85 is a fun processor because despite being so small, it has 8K of flash, and 5 I/O pins, including analogue inputs and PWM ‘ analogue’ outputs. We designed a USB bootloader so you can plug it into any computer and reprogram it over a USB port just like an Arduino. In fact, we even made some simple modifications to the Arduino IDE so that it works like a mini-Arduino board. You can’t stack a big shield on it but for many small & simple projects, the Trinket will be your go-to platform.
This is the 5V Trinket. There are two versions of the Trinket. One is 3V and one is 5V. Both work the same but have different operating logic voltages. Use the 3V one to interface with sensors and devices that need 3V logic, or when you want to power it off of a LiPo battery. The 3V version should only run at 8 MHz. Use the 5V one for sensors and components that can use or require 5V logic. The 5V version can run at 8 MHz or at 16MHz by setting the software-set clock frequency.
Features:
- ATtiny85 on-board, 8K of flash, 512 bytes of SRAM, 512 bytes of EEPROM
- Internal oscillator runs at 8MHz but can be doubled in software for 16MHz
- USB bootloader with a nice LED indicator looks just like a USBtinyISP so you can program it with AVRdude (with a simple config modification) and/or the Arduino IDE (with a few simple config modifications)
- Mini-USB jack for power and/or USB uploading, you can put it in a box or tape it up and use any USB cable for when you want to reprogram.
- We really worked hard on the bootloader process to make it rugged and foolproof, this board won’t up and die on you in the middle of a project!
- ~5.25K bytes available for use (2.75K taken for the bootloader)
Package Includes:
1 x Adafruit Pro Trinket – 5V 16MHz
About Adafruit Pro Trinket –
Adafruit PRO Trinket – 5V 16MHz is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Adafruit, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Adafruit
- SKU: AI1773
- Category: Boards Compatible with Arduino
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Adafruit Pro Trinket – and other products.
Applications
Adafruit Pro Trinket – can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Adafruit Pro Trinket – today and start building.
Adafruit PRO Trinket – 5V 16MHz Overview
The Adafruit PRO Trinket – 5V 16MHz is a compact microcontroller board built around the Atmel ATtiny85. Designed for projects where space and cost are critical, it brings Arduino IDE compatibility to a tiny form factor, making it ideal for embedding into finished designs.
Key Features of Adafruit PRO Trinket – 5V 16MHz
- ATtiny85 MCU running at 16MHz with 5V operation for reliable performance
- 8KB of flash memory and 512 bytes of RAM for lightweight sketch storage
- Five GPIO pins including analog inputs and PWM outputs for sensor and actuator control
- Arduino IDE–programmable via the Adafruit TinyFlash bootloader
- Ultra-compact board size fits into tight enclosures and wearable designs
- Authentic Adafruit product with fast shipping across India from Zbotic
Applications and Use Cases
- Portable LED animation controllers in custom wearables
- Inline sensor modules for temperature, light or motion detection
- Miniature robotics controllers for small servos and motors
- Data-logging nodes for environmental monitoring with I²C sensors
- Interactive art installations requiring compact, low-power brains
- Home automation triggers and relay drivers in constrained spaces
How to Use Adafruit PRO Trinket – 5V 16MHz
Begin by installing the Adafruit AVR boards package in the Arduino IDE, then select “Pro Trinket 5V/16MHz” as your target. Connect the board to your PC via USB, write or modify your sketch, and click “Upload.” Power the Trinket from USB or a regulated 5V supply, and wire your sensors or outputs to the 5 available GPIO pins.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage range does the Pro Trinket support?
This model is designed for a 5V supply and runs its ATtiny85 MCU at 16MHz. Ensure your USB or external power source provides a stable 4.5–5.5V for consistent operation.
How do I upload code to the PRO Trinket using Arduino IDE?
Install Adafruit’s AVR board files via the Boards Manager, select “Pro Trinket 5V/16MHz,” then connect via USB. Click the Upload button—your sketch will compile and load over the built-in TinyFlash bootloader.
How many analog and PWM pins are available?
The ATtiny85 on the PRO Trinket exposes four analog-capable inputs (A0–A3) and two pins that support PWM output, allowing you to read multiple sensors and drive LEDs or motors with variable power.
Arduino Mega 2560 Pinout: All 70 Pins Explained
Understanding the Arduino Mega 2560 pinout is essential for anyone building complex electronics projects. With 70 input/output pins,...
Read More →
Arduino Level 4: WiFi and IoT with ESP32
Arduino Level 4 takes your projects online with ESP32, WiFi, and IoT. The ESP32 is programmed using the...
Read More →
ESP32 Audio Player: I2S DAC Music Streaming
Esp32 Audio Player I2S Dac — this detailed tutorial covers everything from hardware selection to complete working code,...
Read More →Technical Specifications
| Brand | Adafruit |
|---|---|
| Operating Voltage | 5V |
| Frequency | 16MHz |
| SKU | AI1773 |
| Weight | 0.003 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Adafruit PRO Trinket – 5V 16MHz is a versatile boards compatible with arduino used across a wide range of applications including electronics learning, robotics, home automation, sensor interfacing, and motor control.
Common use cases:
- Learning programming and electronics
- Building a line-following robot
- Creating a home automation hub
This product is ideal for students, hobbyists, and electronics beginners.
Technical Tip: Arduino Uno is the standard learning board. Mega offers more pins for complex projects. Nano suits breadboard prototyping.
