4N35 IC – Optocoupler Phototransistor IC
The 4N35 optocoupler is composed of a gallium arsenide infrared LED and a silicon NPN phototransistor. The couplers have Underwriters Laboratories (UL) certification, which means they can withstand a 5300 VRMS isolation test voltage.
This isolation performance is achieved through a double moulding isolation manufacturing process. These families of couplers can also meet the partial discharge isolation specification of DIN EN 60747-5-2(VDE0884)/ DIN EN 60747-5-5 by ordering option 1.
These isolation processes and the ISO9001 quality program ensure the highest isolation performance possible for a commercial plastic phototransistor optocoupler. The devices come in lead formed configuration that is suitable for surface mounting and are available either on tape and reel, or in standard tube shipping containers.
Features:-
Isolation Test Voltage 5300 VRMS
Interfaces with common logic families
Input-output coupling capacitance < 0.5 pF
Industry Standard Dual-in line 6-pin package
Agency Approvals:-
Underwriters Laboratory File #E52744
DIN EN 60747-5-2(VDE0884)
DIN EN 60747-5-5 pending
Available with Option 1
Applications:-
AC mains detection
Reed relay driving
Switch mode power supply feedback
Telephone ring detection
Logic ground isolation
Logic coupling with high frequency noise rejection
The 4N35 IC is an optocoupler phototransistor device that uses a gallium arsenide infrared LED paired with a silicon NPN phototransistor to achieve electrical isolation between input and output. It’s ideal for protecting low-voltage logic circuits from high-voltage spikes and noise.
Key Features of 4N35 IC – Optocoupler Phototransistor IC
UL certified isolation test voltage of 5300 VRMS through double-moulding process
Input-output coupling capacitance below 0.5 pF for minimal signal distortion
Direct interface with common logic families such as TTL and CMOS
Industry-standard dual in-line 6-pin package for easy PCB footprint
Gallium arsenide infrared LED and silicon NPN phototransistor core for reliable switching
Fast shipping from Zbotic across India for rapid prototyping and deployment
Applications and Use Cases
Isolation between microcontroller I/O and high-voltage power stages
Feedback signal coupling in switching power supplies
Noise immunity enhancement in industrial automation and PLC systems
Signal interfacing in telecom line drivers and modems
Voltage domain translation in embedded control boards
How to Use 4N35 IC – Optocoupler Phototransistor IC
Mount the 4N35 IC in its dual in-line footprint and wire the LED input pins with a suitable current-limiting resistor to your control signal. Connect the phototransistor output between your load and supply, observing correct pin orientation. Ensure the LED forward current stays within recommended limits and the output transistor is biased for your logic voltage.
