This is the 7V variant of the 1S 3.7V 7.5A 5MOS BMS Li- ion 18650 Battery Protection Board in Battery Protection Board. Available at Original price was: ₹73.16.₹61.36Current price is: ₹61.36. (₹52.00 + GST) with free shipping across India.
Looking for 18650? 1S 3.7V 7.5A 5MOS BMS Li- ion 18650 Battery Protection Board is available at Zbotic with fast shipping across India.
PRODUCT DESCRIPTION
Li-ion batteries are widely used in a range of indoor and outdoor devices due to their high charge storage capacity. They are more compact, efficient, and offer greater energy density compared to other battery types. However, they do have some limitations that require careful monitoring during both charging and discharging. Discharging a battery below a certain voltage can damage the cell and reduce its overall capacity, while overcharging can present serious risks, including potential explosions.
To prevent these issues, battery protection and charging circuits are essential. This product is a Li-ion single-cell charger and protection circuit designed to charge a single 15 Amp cell or 5 to 6 parallel-connected 2500mAh Li-ion cells. It incorporates MOSFETs to monitor the battery’s condition and protect against overcharging, over-discharging, and short circuits, ensuring safe and reliable operation.
Protection :
- Overcharge protection.
- over-discharge protection.
- short circuit protection.
- overcurrent protection.
Wiring instructions:
- B battery is positive.
- B- battery negative.
- P outputs the positive input for the battery pack.
- P- outputs the negative electrode for the battery pack.
Specification:
| Overcharge detection voltage | 4.25 + 0.05V. |
|---|---|
| Over charge release voltage | 4.23 + 0.05V. |
| Discharge detection voltage : | 2.45 + 0.1V. |
| Ceiling continuous current | 12A. |
| Overcurrent detection current | 7.5A |
| Input Charging voltage | 3.7V |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 8 × 7 × 1 cm |
Package Includes :
1 x 1S 18650 3.7V lithium battery protection plate 5 MOS.
1S 3.7V 7.5A 5MOS BMS Li-ion 18650 Battery Protection Board Overview
The 1S 3.7V 7.5A 5MOS BMS Li-ion 18650 Battery Protection Board is a single-cell management module designed to safeguard 18650 Li-ion batteries against overcharge, over-discharge and overcurrent. It ensures safe charging and discharging by monitoring cell voltage thresholds and interrupting current flow when limits are exceeded.
Key Features of 1S 3.7V 7.5A 5MOS BMS Li-ion 18650 Battery Protection Board
- Overcharge detection at 4.25 ± 0.05 V with release at 4.23 ± 0.05 V
- Over-discharge protection triggers at 2.45 ± 0.1 V to prevent cell damage
- Overcurrent detection set at 7.5 A and continuous current rating up to 12 A
- 5-MOSFET architecture for low heat generation and improved efficiency
- Integrated charging input rated for 3.7 V Li-ion cells
- Fast shipping from Zbotic across India, ready to install
Applications and Use Cases
- DIY power banks built with single 18650 cells
- Portable LED lighting systems requiring safe Li-ion management
- Battery packs for small drones or RC models
- Backup power modules for IoT prototypes (single-cell setups)
- Wearable electronics projects using 3.7 V cells
How to Use 1S 3.7V 7.5A 5MOS BMS Li-ion 18650 Battery Protection Board
Connect the B- and B+ pads to the negative and positive terminals of your 18650 cell, then wire the P- and P+ pads to your charger or load. Ensure polarity is correct before powering up. The board will automatically manage charge/discharge cycles, cutting off current if voltage or current limits are reached.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage range does this protection board support?
This BMS board is designed for a single Li-ion cell with an operating range from 2.45 V (discharge cutoff) up to 4.25 V (overcharge cutoff), ensuring safe cell management.
Can I use this board with other cell types?
No, this board is specifically calibrated for 3.7 V nominal 18650 Li-ion cells. Using different chemistries or voltages may lead to improper protection and potential hazards.
How do I know if overcurrent protection has activated?
When an overcurrent event (above 7.5 A) occurs, the board will instantly disconnect output. Normal operation resumes once the load is removed and the board’s internal circuit resets.
