XH2.54mm 8P Bend Pin Header Connector
Elevate your electronic projects with our XH2.54mm 8P Bend Pin Header Connector pack, containing 5 units designed for reliable connections. These connectors are indispensable components for various applications, including PCB prototyping, breadboarding, DIY electronics projects, and more.
Applications:
- AC power supply to PCs and lab equipment.
- Used in all types of RCs( cars, boats, planes).
- Also used in CCTV connections, pick-ups, etc.
Features:
- Use of electrical fire retardant material.
- Solid and durable.
- Safe and easy to install.
- RoHS compliant.
Specification:
| Model | XH2.54mm 8P |
|---|---|
| Product Type | Bend Pin Header Connector |
| Contact Material | Phosphor Bronze |
| Gender | Male |
| Connector Type | JST – XH |
| No. of Contact Points | 2 |
| Constant Current (A) | 250V |
| Contact Plating | Nickel |
| Operating Temperature Range (°C): | -25 to 85(°C) |
| Dimensional Accuracy (mm) | 27.5 x 8 x 9 |
Package Includes:
- 1 x 8 Pin JST XH 2.54mm Pitch Header Connector– 5Pcs.
XH2.54mm 8P Bend Pin Header Connector – Overview
The XH2.54mm 8P Bend Pin Header Connector is an 8-pin, 2.54 mm pitch PCB header with bent pins, supplied in a pack of 5. Designed for solid and safe wire-to-board connections, it’s ideal for prototyping, custom wiring harnesses, and electronic assemblies requiring reliable mating.
Key Features of XH2.54mm 8P Bend Pin Header Connector –
- 8-pin connector with 2.54 mm (XH series) pitch for standard PCB layouts
- Bent pin design ensures secure solder joints and strain relief on the board
- Electrical fire retardant plastic housing for enhanced safety
- Durable metal contacts for consistent conductivity and low contact resistance
- RoHS compliant construction, free from lead and other hazardous substances
- Pack of 5 genuine units, backed by fast shipping from Zbotic across India
Applications and Use Cases
- Custom power and signal header on DIY PCB prototypes or Arduino shields
- Wire-to-board connections in RC vehicles, drones, and hobby electronics
- Interface link between CCTV camera modules and control boards
- AC power supply wiring inside PC power units and laboratory equipment
- Connector header for 3D printer controller boards and CNC machines
How to Use XH2.54mm 8P Bend Pin Header Connector –
Position the bent-pin header over the PCB pads so that each pin aligns with its corresponding solder pad. Secure the connector in place—using a fixture or tape if needed—then solder each pin from the underside of the board. After soldering, allow the joints to cool before inserting matching female housings or wires into the connector housing for a firm, reliable connection.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the pitch and pin count of this connector?
This header has an XH series 2.54 mm pitch with 8 bent pins, ideal for standard PCB hole spacing.
Can I solder this connector directly onto a PCB?
Yes. The bent pins are designed for through-hole mounting and can be soldered on the PCB underside for a secure mechanical and electrical connection.
What material is used in the housing and contacts?
The housing is made of electrical fire retardant plastic, while the metal pins are durable conductive contacts. The entire assembly is RoHS compliant.
