This is the 54mm variant of the XH2.54mm 10P Bend Pin Header Connector – (Pack of 5) in Battery Connector. Available at Original price was: ₹21.24.₹11.56Current price is: ₹11.56. (₹9.80 + GST) with free shipping across India.
PRODUCT DESCRIPTION
This is a 10 Pin JST XH 2.54mm Pin Header Connector.
Applications:
- AC power supply to PCs and lab equipment.
- Used in all types of RCs( cars, boats, planes).
- Also used in CCTV connections, pick-ups, etc.
Features:
- Use of electrical fire retardant material.
- Solid and durable.
- Safe and easy to install.
- RoHS compliant.
Specification:
| Model | XH2.54mm 10P |
|---|---|
| Product Type | Header Connector |
| Operating Voltage(V) | 250V |
| Plug Type | JST – XH |
| Gender | Male |
| Current Handling Capacity (A) | 3 |
| No. of Contact Points | 2 |
| Contact Material | Phosphor Bronze |
| Contact Plating | Nickel |
| Operating Temperature Range (°C): | -25 to 85(°C) |
| Dimensional Accuracy (mm) | 27.5 x 8 x 9 |
| Shipping Weight | 0.004 kg |
| Shipping Dimensions | 10 × 6 × 2 cm |
Package Includes:
1 x 10 Pin JST XH 2.54mm Pitch Header Connector– 5Pcs.
XH2.54mm 10P Bend Pin Header Connector – Overview
This pack of five 10-pin JST XH 2.54mm pitch male header connectors features bent pins for right-angle PCB mounting. Designed for reliable low-voltage and signal connections, it is ideal for applications ranging from battery assemblies to electronic modules.
Key Features of XH2.54mm 10P Bend Pin Header Connector –
- Pack of 5 genuine JST XH male header connectors with 10 pins each at 2.54mm pitch
- Phosphor bronze contacts with nickel plating ensure good conductivity and corrosion resistance
- Rated for up to 250V and 3A current handling per contact
- Bend pin (right-angle) design simplifies PCB layout and saves board space
- Fire-retardant, RoHS-compliant housing material for safe operation
- Solid and durable construction; safe and easy to install
- Fast shipping from Zbotic with nationwide delivery
Applications and Use Cases
- AC power connections on PC motherboards and lab equipment
- Battery pack interfaces in RC cars, boats, and drones
- Signal and power links in CCTV camera modules and security systems
- Connector blocks in pick-up circuits and audio equipment
- Interfacing sensors and control boards in DIY robotics
How to Use XH2.54mm 10P Bend Pin Header Connector –
Position the bent pins into the PCB drill holes at the desired right-angle orientation, solder each pin securely to the board pads, then slide on the matching 10-pin JST XH housing to establish a reliable wire-to-board connection. Verify alignment before soldering for optimal results.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I mount the connector in both orientations?
The bend pin header is designed for right-angle PCB mounting only. For straight-through connections, use a standard 0° header.
What wiring housing fits this header?
This header mates with any standard 10-pin JST XH series housing and crimp terminals designed for 2.54mm pitch.
Is this connector suitable for high-temperature environments?
Yes, the phosphor bronze contacts and fire-retardant housing are rated to operate safely from –25°C to +85°C.
