This is the 3inch variant of the Waveshare ESP32-S3 4.3inch Capacitive Touch Display Development Board, 800×480, 5-point Touch, 32-bit LX7 Dual-core Processor in ARM Microcontroller. Available at ₹4,337.68 (₹3,676.00 + GST) with free shipping across India.
Waveshare ESP32-S3 4.3inch Capacitive Touch Display Development Board, 800×480, 5-point Touch, 32-bit LX7 Dual-core Processor is a microcontroller development board with 2.4GHz WiFi and BLE 5 support, and integrates high-capacity Flash and PSRAM. The onboard 4.3-inch capacitive touch screen can smoothly run GUI programs such as LVGL. Combined with various peripheral interfaces, suitable for the quick development of the HMI and other ESP32-S3 applications.
Features:
- Equipped with Xtensa 32-bit LX7 dual-core processor, up to 240MHz main frequency.
- Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE), with onboard antenna.
- Built in 512KB of SRAM and 384KB ROM, with onboard 8MB PSRAM and 8MB Flash.
- Onboard 4.3inch capacitive touch display, 800×480 resolution, 65K color.
- Supports capacitive touch control via I2C interface, 5-point touch with interrupt support.
- Onboard CAN, RS485, I2C interface and TF card slot, integrates full-speed USB port.
- Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios.
Specification:
| Item Type: | Development Board |
|---|---|
| Model Name | Waveshare ESP32-S3 4.3inch Capacitive Touch Display Development Board, 800×480, 5-point Touch, 32-bit LX7 Dual-core Processor |
| Processor | Xtensa 32-bit LX7 dual-core, up to 240MHz |
| Wireless Functions | 2.4GHz Wi-Fi (802.11 b/g/n), Bluetooth 5 (LE) |
| Memory: | 512KB SRAM, 384KB ROM, 8MB PSRAM, 8MB Flash |
| Display Resolution: | 800 x 480 |
| Display Size (Inch): | 4.3 |
| Display Type | Capacitive Touch |
| Interface: | CAN, RS485, I2C, TF card slot, Full-speed USB |
Package includes:
1 x ESP32-S3-Touch-LCD-4.3
2 x HY2.0 2P to 2PIN male cable 10cm
1 x HY2.0 2P to 3PIN male cable 10cm
1x HY2.0 2P to 4PIN male cable 10cm
1 x Standoff pack
Technical Specifications
| Brand | WAVESHARE |
|---|---|
| Model | ESP32-S3 |
| Display Size | 4.3" |
| Resolution | 800x480 |
| Package Quantity | 7 pcs |
| SKU | AI6710 |
| Weight | 0.21 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Waveshare ESP32-S3 4.3inch Capacitive Touch Display Development Board, 800×480, 5-point Touch, 32-bit LX7 Dual-core Processor is a versatile arm microcontroller used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
