TOBITEK BTW1(4006) BLDC Motor
Description:
The TOBITEK BTW1 (4006) BLDC Motor is a high-efficiency brushless DC motor designed for UAVs and drone propulsion systems. It is engineered to deliver stable thrust, smooth operation, and reliable performance for lightweight aerial applications. With a 380 KV rating and support for a 6S battery, it is suitable for drone platforms requiring efficient power delivery and controlled flight performance.
Reliable brushless motor designed for surveillance drones with extended endurance and stable performance.
Specifications:
| Category | Specification | Details |
|---|---|---|
| System | Maximum Thrust | 2 kgf |
| System | KV Rating | 400 KV |
| System | Total Weight | 84 g |
| System | Take-off Weight | 1–1.2 kg |
| System | Voltage Range | 6S |
| Motor | Stator Size | Ø40 × 06 mm |
| Motor | Motor Size | Ø45 × 32.1 mm |
| Motor | Maximum Power | 380 W |
| Motor | Maximum Current | 16 A |
| Motor | Efficiency | TBD |
| Motor | Temperature Range | TBD |
| Motor | Bearing Type | TBD |
| Motor | Magnet Material | TBD |
| ESC | Model | Reflex Drive D Series (40A, 2S–6S) |
| ESC | Voltage Range | 2S–6S |
| ESC | Continuous Current | 40 A |
| ESC | Burst Current | TBD |
| ESC | Weight | TBD |
| Propeller | Model | R1552 |
| Propeller | Weight | 27 g |
Features:
- High-efficiency brushless motor design.
- Stable thrust for reliable drone operation.
- Lightweight construction for UAV integration.
- Designed for compatibility with suitable ESCs and propellers.
- Supports 6S battery-powered drone propulsion systems.
Applications:
- Surveillance Drones
- Mapping Drones
Pacakge Includes:
1xTOBITEK BTW1(4006) BLDC Motor
Drone Waypoint Mission Planning: ArduPilot & Mission Planner Guide
Drone Waypoint Mission Planning: ArduPilot & Mission Planner Guide Autonomous drone flights powered by GPS waypoints are transforming...
Read More →
Motor Driver Shield for Arduino: Top 5 Picks India 2026
Table of ContentsWhy Use a Motor Driver Shield?Types of Motor Driver ShieldsTop 5 Motor Driver Shields in India...
Read More →
Drone Power Line Inspection: Commercial Application
Table of Contents Understanding Drone Power Line Inspection Key Components and Requirements Step-by-Step Setup Guide Configuration and Optimisation...
Read More →Technical Specifications
| Brand | TOBITEK |
|---|---|
| SKU | AI5164 |
| Weight | 0.0 kg |
| Availability | Out of Stock |
Applications & Use Cases
The TOBITEK BTW1(4006) BLDC Motor is a versatile drone motor used across a wide range of applications including FPV racing drones, agricultural spray drones, aerial photography platforms, and custom multirotor builds.
Common use cases:
- Replacement motor for crashed or worn-out drone
- Building a custom quadcopter or hexacopter from scratch
- Upgrading to a more efficient motor for longer flight times
This product is ideal for drone builders, FPV pilots, and agricultural drone operators.
Technical Tip: When selecting a drone motor, match the KV rating to your propeller size and battery voltage. Lower KV = larger props + more efficiency; higher KV = smaller props + more speed.
