P-Series T-Motors are built to perform reliably in demanding environments, offering exceptional durability and long service life. The P80 KV120 Tiger motors generate up to 17kg of thrust, with impact resistance, anti-corrosion coils, and low noise.
Featuring a 36N42P configuration, P-Series T-Motors reduce motor vibration during operation, minimizing wear, extending service life, and reducing noise. These Tiger motors provide smoother performance than standard motors, even at maximum throttle.
Package include
1 x T-Motor P series 80 120kV
T-Motor P series 80 120kV Overview
The T-Motor P series 80 120kV is a high-torque, low-RPM brushless motor designed for heavy-lift multirotor drones. Engineered with impact-resistant materials and anti-corrosion coils, it delivers up to 17 kg of thrust while operating quietly and reliably in demanding environments.
Key Features of T-Motor P series 80 120kV
- 36N42P stator configuration reduces vibration, noise, and wear for smoother operation
- Generates up to 17 kg of thrust with optimal propeller matching
- Impact-resistant housing and anti-corrosion coil coating for enhanced durability
- Low noise profile even at maximum throttle for stable aerial footage
- Long service life under continuous heavy-load conditions
- Genuine product, fast shipping from Zbotic
Applications and Use Cases
- Heavy-lift cinematography drones carrying professional camera gimbals
- Industrial inspection UAVs for powerline and infrastructure surveys
- Agricultural spraying platforms requiring stable low-RPM thrust
- Payload delivery drones transporting medical supplies or cargo
- Search and rescue multirotors needing reliable long-duration flights
- Research and prototype aircraft in academic or R&D projects
How to Use T-Motor P series 80 120kV
Mount the P80 120kV motor to a compatible 650–800 mm frame using the included mounting holes, then solder power leads to a suitable 12S-capable ESC (80 A or higher). Attach recommended 26″–28″ carbon propellers, calibrate ESC timing to “medium” or “high,” and perform a break-in cycle at low throttle. Regularly inspect bearings and clean coils with compressed air to maintain peak performance.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What propeller size is recommended for the T-Motor P series 80 120kV?
We recommend 26″ to 28″ reinforced carbon propellers to match the motor’s low KV rating and achieve maximum thrust and efficiency.
Which ESC compatibility is required for P80 KV120?
Pair the motor with a 12S-capable electronic speed controller rated at 80 A or above to ensure stable power delivery and responsive throttle control under heavy loads.
How does the 36N42P configuration benefit performance?
The 36 stator slots and 42 magnetic poles design minimize vibration and cogging torque, resulting in smoother operation, reduced noise, and extended motor lifespan during continuous use.
Stepper Motor Power Supply: Choosing Voltage & Amperage
Table of ContentsIntroductionStepper Motor Electrical BasicsUnderstanding Rated Voltage vs Operating VoltageCurrent Rating and Why It MattersThe Driver's Role...
Read More →
Vtail vs X Frame FPV: Aerodynamic Design Comparison
Table of Contents FPV Frame Basics: Arms, Geometry, and Airflow The X Frame: The Universal Standard The Vtail...
Read More →
Stepper Motor Datasheet Reading: Understanding Phase, Current & Steps
Table of Contents Why Reading the Datasheet Matters Step 1: Identify the Motor Type Step 2: Step Angle...
Read More →Technical Specifications
| Brand | T -Motor |
|---|---|
| KV Rating | 120KV |
| SKU | AI6207 |
| Availability | In Stock |
Applications & Use Cases
The T-Motor P series 80 120kV is a versatile drone motor used across a wide range of applications including FPV racing drones, agricultural spray drones, aerial photography platforms, and custom multirotor builds.
Common use cases:
- Replacement motor for crashed or worn-out drone
- Building a custom quadcopter or hexacopter from scratch
- Upgrading to a more efficient motor for longer flight times
This product is ideal for drone builders, FPV pilots, and agricultural drone operators.
Technical Tip: When selecting a drone motor, match the KV rating to your propeller size and battery voltage. Lower KV = larger props + more efficiency; higher KV = smaller props + more speed.
