This is the Red variant of the MAD CO – FS 2407 SPARK FPV Drone motor (Red) 2600KV – 4S in Drone Motor. Available at ₹3,258.22 (₹2,761.20 + GST) with free shipping across India.
MAD CO – FS 2407 SPARK FPV Drone motor (Red) 2600KV – 4S
Description:
The MAD CO FS 2407 SPARK FPV Drone Motor (Red) 2600KV – 4S is a high-performance motor designed for FPV racing and freestyle flying. With a 2600KV rating, it is optimized for 4S batteries, offering fast throttle response and high-speed capabilities. The motor features a 29×32.3mm size, 12N14P winding configuration, and 4mm shaft diameter. It includes precision rotor balancing (≤5 mg) for smooth operation, and the M5 nut mounting holes make propeller installation secure. The motor comes with 150mm 20# AWG silicone wire and is available in a vibrant red color, making it both functional and visually striking.
Features:
- KV Rating: 2600KV, optimized for 4S batteries for high-speed performance.
- Rotor Balance: Ensures smooth operation with high precision (≤5 mg).
- Mounting Holes: M5 Nut for easy propeller attachment.
- Cable: Durable, flexible 150 mm, 20# AWG silicone cable.
Specification:
| Model Name: | MAD Spark FS2407 V1.0 |
|---|---|
| Manufacturer: | |
| Motor Size (mm): | D:29 × 32.3 |
| Shaft Diameter | IN: 4 mm |
Package Include:
1 x MAD CO – FS 2407 SPARK FPV Drone motor (Red) 2600KV – 4S
Agricultural Drone Spraying System: Components and Setup
A well-designed agricultural drone spraying system is the heart of any crop protection drone, directly determining spray coverage,...
Read More →
Servo Motor Position Feedback: Potentiometer & Encoder Methods
Standard RC servo motors (SG90, MG996) have built-in position feedback through an internal potentiometer. The servo driver electronics...
Read More →
Custom Flight Controller Build with STM32
Building a custom flight controller with STM32 is the ultimate drone electronics project. You design the PCB, select...
Read More →Technical Specifications
| Brand | MAD COMPONENTS |
|---|---|
| Cell Configuration | 4S |
| KV Rating | 2600KV |
| Color | Red |
| SKU | AI8120 |
| Weight | 0.02 kg |
| Availability | Out of Stock |
Applications & Use Cases
The MAD CO – FS 2407 SPARK FPV Drone motor (Red) 2600KV – 4S is a versatile drone motor used across a wide range of applications including FPV racing drones, agricultural spray drones, aerial photography platforms, and custom multirotor builds.
Common use cases:
- Replacement motor for crashed or worn-out drone
- Building a custom quadcopter or hexacopter from scratch
- Upgrading to a more efficient motor for longer flight times
This product is ideal for drone builders, FPV pilots, and agricultural drone operators.
Technical Tip: When selecting a drone motor, match the KV rating to your propeller size and battery voltage. Lower KV = larger props + more efficiency; higher KV = smaller props + more speed.
