Looking for Kp Original 902232 Battery? KP Original 902232 1500mAh 3.7Vsingle cell Rechargeable LiPo Battery is available at Zbotic with fast shipping across India.
902232 3.7V 1500mAh Lithium Polymer (LiPo) Rechargeable Battery
Product Description:
The 902232 3.7V Lithium Polymer (LiPo) rechargeable battery is engineered to provide high energy density and excellent performance for a wide range of applications. With a robust capacity of 1500mAh, this battery is perfect for powering devices such as wearables, drones, portable gadgets, and more. Its compact design and reliable discharge rate make it an ideal choice for developers and hobbyists looking for efficient energy solutions.
Technical Specifications:
- Model Number: 902232
- Type: Lithium Polymer (LiPo)
- Nominal Voltage: 3.7V
- Capacity: 1500mAh
- Dimensions:
- 33mm x 22mm x 9.0mm (L.B.H.)
- Weight: Approximately 40 grams
- Discharge Rate: 1C (maximum continuous)
- Charge Rate: Up to 1C (maximum)
- Charging Voltage: 4.2V ± 0.05V
- Discharge Cut-off Voltage: 3.0V
- Cycle Life: Approximately 300-500 cycles (depending on usage practices)
- Connector Type: JST connector (custom options available upon request)
- Operating Temperature Range:
- Charge: 0°C to 45°C
- Discharge: -20°C to 60°C
- Storage Conditions: Store at 40-60% charge in a cool, dry place for optimal lifespan.
- Safety Features:
- Overcharge protection
- Over-discharge protection
- Short-circuit protection
- Thermal protection systems
Application Areas:
- Wearable technology (fitness devices, smartwatches)
- Consumer electronics (audio devices, cameras)
- Drones and robotics
- Internet of Things (IoT) devices
- Medical equipment (portable monitoring devices)
Package Includes:
- 1 x 902232 1500mAh 3.7V LiPo Battery
KP Original 902232 1500mAh 3.7V single cell Rechargeable Overview
The KP Original 902232 is a compact single-cell Lithium Polymer (LiPo) battery delivering 3.7 V nominal voltage and 1500 mAh capacity. Designed for projects requiring reliable, lightweight power, it suits applications like micro drones, wearable electronics, and portable gadgets.
Key Features of KP Original 902232 1500mAh 3.7V single cell Rechargeable
- Nominal voltage of 3.7 V and robust 1500 mAh capacity in a micro form factor
- Compact dimensions (33 × 22 × 9 mm) and light weight (~40 g) for space-constrained designs
- 1C continuous discharge rate supports up to 1.5 A draw for stable performance
- Durable LiPo chemistry offering high energy density and consistent delivery
- Genuine KP Original cell with reliable quality and safety standards
- Fast shipping from Zbotic across India with secure packaging
Applications and Use Cases
- Power source for micro UAVs and nano quadcopters
- Energy supply for wearable fitness trackers or smart patches
- Backup battery in small wireless sensor modules
- Portable power pack for microcontroller-based prototypes
- Drive small handheld devices like mini Bluetooth speakers
- Integration into DIY robotics and remote-control toys
How to Use KP Original 902232 1500mAh 3.7V single cell Rechargeable
Connect the KP Original 902232 cell to a compatible LiPo charger set to a maximum charge voltage of 4.2 V and charging current at or below 1.5 A. Observe correct polarity when wiring into your device, secure the battery with double-sided tape or heat-shrink tubing, and avoid puncturing or compressing the pack during installation.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum continuous discharge current of the 902232 battery?
The KP Original 902232 cell is rated at a 1C continuous discharge rate, supporting up to 1.5 A constant current draw without compromising performance.
Can I charge this KP Original 902232 cell with a standard LiPo charger?
Yes. Use any LiPo-compatible charger configured to a 4.2 V end-of-charge voltage. Limit the charge current to 1.5 A or below for optimal battery life.
How should I store the battery when it’s not in use?
Store the battery at around 40–60% charge in a cool, dry place away from direct sunlight and extreme temperatures. Do not leave it fully discharged or fully charged for extended periods.
Sodium-Ion Battery: Next Generation Energy Storage
The sodium-ion battery is emerging as a game-changing energy storage technology that could reshape India's battery landscape. Using...
Read More →
Battery Voltage Monitor: Low Battery Alert System
Table of ContentsWhy Monitor Battery Voltage Simple Voltage Divider Method Using INA219 for Precision Monitoring LED Indicator Modules...
Read More →
UPS for Raspberry Pi: 18650 or LiPo HAT Comparison
UPS for Raspberry Pi: 18650 or LiPo HAT Comparison Power outages are a real challenge in India, making...
Read More →Technical Specifications
| Brand | KP |
|---|---|
| Battery Capacity | 1500mAh |
| Interface / Protocol | BLE |
| SKU | AI6806 |
| Weight | 0.02 kg |
| Availability | Out of Stock |
Applications & Use Cases
The KP Original 902232 1500mAh 3.7Vsingle cell Rechargeable LiPo Battery is a versatile single cell micro lipo battery used across a wide range of applications including FPV drones, RC vehicles, portable electronics, robotics, and airsoft guns.
Common use cases:
- Powering an FPV racing drone
- Running a high-current RC car
- Portable power for field robotics
This product is ideal for drone pilots, RC enthusiasts, and robotics builders.
Technical Tip: Never discharge below 3.5V per cell. Store at 3.8V per cell. Always use a balance charger and never leave charging unattended. Use a LiPo bag for safety.
