This is the CCW rotation variant of the Hobbywing X6 Plus Motor CCW in Drone Kits. Available at ₹11,613.56 (₹9,842.00 + GST) with free shipping across India.
Looking for X6 Plus Motor Ccw? Hobbywing X6 Plus Motor CCW is available at Zbotic with fast shipping across India.
The X6 brushless power system is designed for agricultural drones, capable of supporting loads between 3 to 5 kg per axis. It can deliver thrust up to 11.9 kg and is compatible with 28/30 mm carbon fiber tube arms. With an IPX7 rating, this system is waterproof and dustproof, providing resilience against rain, pesticides, salt spray, sand, dust, mud, and high temperatures.
The Hobbywing X6 Plus incorporates advanced algorithms for optimizing the FOC ESC and motor system, ensuring a balanced operation. It features multiple safety protections, including power-on self-detection, abnormal voltage detection, over-current protection, and motor lock-up prevention, along with real-time data output functionality.
| Voltage(V) | Propeller (Inch) | Throttle (%) | Thrust(g) | Current(A) | Power Input(W) | Speed (RPM) | Efficiency(g/W) | Torque(N·m) | Power Output(W) | Temperature(℃) |
|---|---|---|---|---|---|---|---|---|---|---|
| 46V (12S LiPo) | MFP 24×8.0 | 35% | 1499 | 2.4 | 112.9 | 1960 | 13.2 | 0.49 | 88.1 | / |
| 37% | 2001 | 3.6 | 168.6 | 2254 | 11.9 | 0.59 | 134.3 | |||
| 39% | 2498 | 4.9 | 228.4 | 2509 | 10.9 | 0.72 | 184.6 | |||
| 42% | 2498 | 4.9 | 228.4 | 2509 | 10.9 | 0.72 | 185.9 | |||
| 45% | 2997 | 6.3 | 293.3 | 2740 | 10.2 | 0.81 | 240.0 | |||
| 48% | 3500 | 8.0 | 371.3 | 2964 | 9.4 | 0.92 | 305.0 | |||
| 51% | 4001 | 9.7 | 449.0 | 3158 | 8.9 | 1.02 | 370.3 | |||
| 54% | 4998 | 13.5 | 623.5 | 3528 | 8.0 | 1.15 | 515.8 | |||
| 57% | 5500 | 15.6 | 723.1 | 3705 | 7.6 | 1.25 | 599.4 | |||
| 60% | 6003 | 17.6 | 815.1 | 3870 | 7.3 | 1.38 | 676.6 | |||
| 63% | 6500 | 19.9 | 919.7 | 4017 | 7.0 | 1.46 | 763.9 | |||
| 66% | 7005 | 22.1 | 1021.9 | 4163 | 6.8 | 1.55 | 848.3 | |||
| 69% | 7504 | 24.9 | 1150.9 | 4308 | 6.5 | 1.72 | 953.9 | |||
| 72% | 7999 | 27.4 | 1267.4 | 4460 | 6.3 | 1.82 | 1047.9 | |||
| 75% | 8999 | 32.9 | 1522.9 | 4731 | 5.9 | 2.10 | 1255.4 | |||
| 78% | 9505 | 36.1 | 1671.1 | 4866 | 5.7 | 2.28 | 1372.8 | |||
| 81% | 10000 | 38.6 | 1787.8 | 4960 | 5.6 | 2.34 | 1462.2 | |||
| 84% | 10503 | 42.6 | 1970.1 | 5113 | 5.3 | 2.49 | 1606.1 | |||
| 87% | 10994 | 45.5 | 2104.5 | 5221 | 5.2 | 2.64 | 1709.4 | |||
| 90% | 11494 | 48.8 | 2258.3 | 5339 | 5.1 | 2.77 | 1828.2 | |||
| 100% | 11852 | 51.8 | 2392.1 | 5439 | 4.9 | 3.25 | 1853.1 |
Features:
- Simple and convenient: Simple assembly, easy to install and disassemble.
- Quality craftsmanship: The shell of this product adopts quality craftsmanship with exquisite workmanship, which is a perfect accessory for your RC toy.
- Strong stability: The motor adopts a new design with high endurance, stable connection, and strong stability.
- Very stable: The motor is extremely stable and will work with less impact.
Specification-
| Motor Type | CCW |
|---|---|
| Thrust Limitation | 11.8kg/Axis (46V, Sea Level) |
| Weight Lift | 3.5-5.5kg/Axis (46V, Sea Level) |
| LiPo Battery Cell Count | 12-14S |
| Motor KV | 150rpm/V |
| Stator Size (mm) | 62×18 |
| Bearing | Imported from Japan |
| Operating Temperature (°C): | -20~50 |
| IP Rating | IPX6 |
| Compatible Propellers Size (inch) | 2480 |
| Shipping Weight | 1.05 kg |
| Shipping Dimensions | 30 × 20 × 10 cm |
Note: Product Images are shown for illustrative purposes only and may differ from the actual product.
Package Includes:
1 x Hobbywing X6 Plus Motor – CCW
Hobbywing X6 Plus Motor CCW Overview
The Hobbywing X6 Plus Motor CCW is a high-thrust brushless motor designed specifically for agricultural and heavy-lift multirotor drones. With a 150 rpm/V KV rating and CCW rotation, it delivers reliable performance for payloads up to 5.5 kg per axis at sea level.
Key Features of Hobbywing X6 Plus Motor CCW
- CCW rotation motor with 150 rpm/V KV rating for stable, balanced thrust.
- Max thrust of 11.8 kg per axis at 46 V (sea level) supports heavy-lift applications.
- Recommended takeoff weight of 3.5–5.5 kg per axis; ideal for agricultural spraying and mapping.
- Compatible with 12–14S LiPo battery packs for extended flight times.
- IPX7 waterproof and dustproof rating resists rain, pesticides, salt spray, sand and mud.
- Built-in safety protections: power-on self-check, over-current protection, abnormal voltage detection and motor lock-up prevention.
- Stator dimensions of 62 × 18 mm and compatibility with 28/30 mm carbon fiber tube arms.
- Fast shipping across India from Zbotic.
Applications and Use Cases
- Agricultural spraying drones carrying liquid fertilizers or pesticides.
- Precision mapping and surveying UAVs operating in dusty or wet conditions.
- Environmental monitoring drones that sample air or water in remote areas.
- Heavy-lift photography and cinematography multirotors requiring stable, high-thrust propulsion.
- Research UAV platforms with payloads between 3.5–5.5 kg per axis.
- Disinfection drones for sanitation tasks in industrial or urban environments.
How to Use Hobbywing X6 Plus Motor CCW
Mount the CCW motor onto a compatible 28 mm or 30 mm carbon fiber tube arm, secure with supplied hardware, and connect to a Hobbywing-compatible FOC ESC. Install your 12–14S LiPo battery, configure ESC settings via the Hobbywing programmer, and assign the motor’s CCW rotation direction in your flight controller. Perform a self-test at low throttle, then proceed with calibration and regular inspections to ensure optimal performance and cooling.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum thrust of the X6 Plus Motor CCW?
At 46 V and sea level, the motor can deliver up to 11.8 kg of thrust per axis, making it ideal for payloads between 3.5 and 5.5 kg.
Which battery configuration works best with this motor?
The Hobbywing X6 Plus Motor CCW is optimized for 12–14S LiPo battery packs, providing the voltage needed to achieve peak thrust and efficiency.
Can I use this motor in wet or dusty environments?
Yes, with an IPX7 waterproof and dustproof rating, the motor is protected against immersion in water up to 1 m for 30 minutes and resists dust, mud, pesticides and salt spray.
