Looking for Mkr1000 Wifi Without? Arduino MKR1000 WIFI without headers is available at Zbotic with fast shipping across India.
Arduino MKR1000 has been designed to offer a practical and cost effective solution for makers seeking to add Wi-Fi connectivity to their projects with minimal previous experience in networking. It is based on the Atmel ATSAMW25 SoC (System on Chip), that is part of the Smart Connect family of Atmel Wireless devices, specifically designed for IoT projects and devices. The Arduino MKR1000 combines the functionality of the Zero and the Wi-Fi Shield. This is an ideal board for makers that want to design IoT projects with minimal previous experience in networking.
It features the Atmel ATSAMW25 SoC that is part of the Smart Connect family of Atmel Wireless devices that are specifically designed for IoT projects and devices. The ATSAMW25 is composed of three main blocks; The SAMD21 Cortex-M0+ 32-bit low power ARM MCU, the WINC1500 low power 2.4 GHz IEEE 802.11 b/g/n Wi-Fi, and the ECC508 Crypto Authentication. The MKR1000 includes a Li-Po charging circuit that allows it to run on battery power or external 5V charging the Li-Po battery while running on external power, where switching sources is automatically done.
It has similar computation to the Zero board, rich set of I/O interfaces, low power Wi-Fi with a Crypto chip for secure communication and ease of use of the Arduino Software (IDE) for code development and programming, making all these features the preferred choice for IoT battery-powered projects in a compact form factor.
This version is the MKR1000 without headers. Check out the MKR1000 with Headers.
Features:
-
- SAMD21 Cortex – M0+ 32-bit low power ARM MCU
- 5V board power supply
- Supports Li-Po cell, 3.7V, 700mAh minimum
- 8 digital I/O pins
- 12 PWM pins
- 7 analog input pits (ADC 8/10/12 bit)
- 1 analog output pins (DAC 10-bit)
- 8 external interrupts
- 256 KB Flash memory
- 32 KB SRAM
- 32.768 kHz (RTC) / 48 MHz clock speed
Packages Includes:
1 x Arduino MKR1000 WIFI without headers
About Mkr1000 Wifi Without
Arduino MKR1000 WIFI without headers is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Arduino, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Arduino
- SKU: AI1989
- Category: Original Arduino Boards
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Mkr1000 Wifi Without and other products.
Applications
Mkr1000 Wifi Without can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Mkr1000 Wifi Without today and start building.
About Mkr1000 Wifi Without
Arduino MKR1000 WIFI without headers is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Arduino, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Arduino
- SKU: AI1989
- Category: Other Measuring Instrument
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Mkr1000 Wifi Without and other products.
Applications
Mkr1000 Wifi Without can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Mkr1000 Wifi Without today and start building.
Arduino MKR1000 WIFI without headers Overview
The Arduino MKR1000 WIFI without headers is a compact development board combining a 32-bit ARM Cortex-M0+ SAMD21 microcontroller with an integrated Atmel ATSAMW25 Wi-Fi module. Designed for makers and IoT enthusiasts, it provides 8 digital I/O lines, a 5V USB supply and a dedicated Li-Po battery connector (3.7V, ≥700mAh) for portable Wi-Fi-enabled projects.
Key Features of Arduino MKR1000 WIFI without headers
- Atmel ATSAMW25 SoC: integrates SAMD21 Cortex-M0+ MCU and Wi-Fi radio
- Low-power 32-bit ARM core running at 48 MHz for efficient processing
- 8 digital I/O pins compatible with 3.3V logic levels
- 5V USB power plus JST Li-Po connector supporting 3.7V cells (≥700mAh)
- PCB only—no pre-soldered headers, ideal for custom layouts
- Genuine Arduino board with fast shipping across India from Zbotic
Applications and Use Cases
- Wireless sensor nodes for environmental monitoring
- Home automation controllers with battery backup
- Wi-Fi enabled data loggers for labs or field work
- Prototyping connected devices without bulky shields
- Educational projects teaching embedded Wi-Fi networking
- Portable wearables requiring low-power wireless comms
How to Use Arduino MKR1000 WIFI without headers
Begin by soldering your choice of male or female headers onto the board’s 2.54 mm pads. Install the “Arduino SAMD” and “WiFi101” packages in the Arduino IDE, then select “Arduino MKR1000” under Tools > Board. Power the board via USB or a 3.7 V Li-Po cell, include WiFi101.h in your sketch, configure SSID/password, compile and upload to enable Wi-Fi connectivity.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I solder my own headers on the Arduino MKR1000 WIFI without headers?
Yes. The board ships without soldered headers so you can attach straight or right-angle male/female headers to suit breadboards, shields or custom enclosures.
How do I power the MKR1000 WIFI board with a Li-Po battery?
The MKR1000 features a JST-compatible Li-Po connector for a 3.7 V cell (minimum 700 mAh). Plug in your battery and the onboard charger will manage safe charging whenever USB power is applied.
Which library do I use to connect to Wi-Fi on the MKR1000?
Use the “WiFi101” library available in the Arduino IDE’s Library Manager. After selecting “Arduino MKR1000” under Tools > Board, include WiFi101.h in your sketch to initialize the module and manage network connections.
