Looking for 01s Module? Ai-Thinker Ai-WB2-01S Module is available at Zbotic with fast shipping across India.
Ai-WB2-01S is a Wi-Fi & BLE module developed by Shenzhen Ai-Thinker Technology Co., Ltd. This module is equipped with BL602 chip as the core processor and supports Wi-Fi 802.11b/g/n protocol and BLE 5.0 protocol. The BL602 chip has a built-in 32-bit RISC CPU with low power consumption and 276KB RAM. It can be widely used in the Internet of Things (IoT), mobile devices, wearable electronic devices, smart homes, and other fields.
Features:
- DIP-8 package
- Supports IEEE 802.11 B/g/n protocol
- Wi-Fi security supports WPS/WEP/WPA/WPA2 Personal/WPA2 Enterprise/WPA3
- Supports 20MHz bandwidth with a maximum speed of 72.2 Mbps.
- Bluetooth 5.0, Bluetooth Mesh
- Supports Station + BLE mode, Station + SoftAP + BLE mode
- Supports 32-bit RISC CPU and 276KB RAM
- Secure Startup supports Images with ECC-256 signatures
- Supports real-time AES decryption (OTFAD) in QSPI and SPI Flash, and supports AES
128 CTR mode - Supports AES 128, 192, and 256-bit encryption engines
- Supports SHA-1/224/256
- Support True Random Number Generator (TRNG)
- Public Key Accelerator (PKA), supports a large number of basic operations, and software provides
a signature, verification, and other application program interface - Supports UART, PWM,ADC, and GPIO
- Integrated Wi-Fi MAC/BB/RF/PA/LNA/BT
- Supports multiple sleep modes with a deep sleep current of 12μA
- Universal AT instruction for a quick start
- Supports secondary development and integrates Windows and Linux development
environments
Specifications:
- Model: Ai-WB2-01S
- Package: DIP-8
- Size: 14.5*24.5*11.2(±0.2)mm
- Antenna on-board: PCB antenna
- Frequency: 2400 ~ 2483.5MHz
- Operating temperature: -40℃ ~ 85℃
- Storage temperature: -40℃ ~ 125℃, < 90%R
- Power supply Power supply voltage: 2.7V ~ 3.6V, power supply current
≥500mA - Interface: UART/GPIO/ADC/PWM
- IO: 3
- UART: rate Default value: 115200 bps
- Security: WPS/WEP/WPA/WPA2 Personal/WPA2 Enterprise/WPA3
- Flash: Default 2MByte Support expansion
Datasheet:
Package Includes:
1 x Ai-Thinker Ai-WB2-01S Module
About 01s Module
Ai-Thinker Ai-WB2-01S Module is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Ai- Thinker, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Ai- Thinker
- SKU: AI1673
- Category: Ai Thinker ESP Modules
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about 01s Module and other products.
Applications
01s Module can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your 01s Module today and start building.
About 01s Module
Ai-Thinker Ai-WB2-01S Module is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Ai- Thinker, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Ai- Thinker
- SKU: AI1673
- Category: USB Interface Module
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about 01s Module and other products.
Applications
01s Module can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your 01s Module today and start building.
Ai-Thinker Ai-WB2-01S Module Overview
Ai-Thinker Ai-WB2-01S Module is a compact DIP-8 Wi-Fi & BLE 5.0 communication module based on the BL602 chip. It provides robust wireless connectivity with multiple security protocols for IoT, smart home and wearable applications.
Key Features of Ai-Thinker Ai-WB2-01S Module
- Compact DIP-8 package measuring 14.5 × 24.5 × 11.2 mm with onboard PCB antenna
- Dual-radio support: Wi-Fi 802.11b/g/n (20 MHz, up to 72.2 Mbps) and Bluetooth 5.0 with Mesh capability
- Secure connectivity: WPS, WEP, WPA/WPA2 Personal & Enterprise, and WPA3
- Built-in 32-bit RISC CPU and 276 KB RAM on the BL602 chip for efficient processing
- Operates in the 2.4 GHz ISM band (2400 – 2483.5 MHz) for global compatibility
- Fast shipping across India from Zbotic with genuine modules and prompt delivery
Applications and Use Cases
- Wireless sensor nodes in smart agriculture or environmental monitoring systems
- BLE mesh networking for smart lighting and building automation
- Wi-Fi connectivity in portable devices, fitness trackers and wearables
- IoT gateways for collecting and relaying data to cloud services
- Home automation controllers for smart switches, locks and appliances
- Prototyping platforms and development boards requiring a 2.4 GHz wireless link
How to Use Ai-Thinker Ai-WB2-01S Module
Place the Ai-WB2-01S into a standard DIP-8 socket or solder directly onto your PCB, then supply it with a stable 3.3 V rail. Use the BL602 SDK or AT-command firmware via UART interface to configure Wi-Fi/BLE parameters, flash your application code, and leverage the module’s GPIOs for sensor and peripheral control.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Which wireless standards are supported by the Ai-WB2-01S?
This module supports IEEE 802.11b/g/n Wi-Fi in the 2.4 GHz band at up to 72.2 Mbps and Bluetooth 5.0, including Bluetooth Mesh for robust network topologies.
How do I program and configure the Ai-WB2-01S?
You can program the BL602 chip using the official BL602 SDK via the UART bootloader or SPI. Zbotic provides guidance on setting up the development environment and flashing firmware.
What are the power requirements for this module?
The Ai-WB2-01S operates from a single 3.3 V supply. Ensure your design provides a stable 3.3 V regulator capable of delivering peak currents during Wi-Fi transmission.
Technical Specifications
| Brand | Ai- Thinker |
|---|---|
| Model | WB2-01S |
| SKU | AI1673 |
| Weight | 0.015 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Ai-Thinker Ai-WB2-01S Module is a versatile ai thinker esp modules used across a wide range of applications including WiFi-enabled IoT devices, smart home sensors, web servers, mesh networks, and wireless data logging.
Common use cases:
- Connecting an Arduino project to WiFi
- Building a smart plug or switch
- Creating a wireless sensor network
This product is ideal for IoT developers, home automation enthusiasts, and embedded engineers.
Technical Tip: ESP32 supports both WiFi and Bluetooth. ESP8266 is WiFi-only but more affordable. Both are programmable via Arduino IDE or ESP-IDF.
