Looking for Nrf52840 Sense? Adafruit Feather nRF52840 Sense is available at Zbotic with fast shipping across India.
The Adafruit Feather Bluefruit Sense takes our popular Feather nRF52840 Express and adds a smorgasbord of sensors to make a great wireless sensor platform. This Feather microcontroller comes with Bluetooth Low Energy and native USB support featuring the nRF52840! This Feather is an ‘all-in-one’ Arduino-compatible + Bluetooth Low Energy with built-in USB plus battery charging. With native USB it works great with CircuitPython, too.
Like the Feather nRF52840, this chip comes with Arduino IDE support- you can program the nRF52840 chip directly to take full advantage of the Cortex-M4 processor, and then calling into the Nordic SoftDevice radio stack when you need to communicate over BLE. Since the underlying API and peripherals are the same for the ‘832 and ‘840, you can supercharge your older nRF52832 projects with the same exact code, with a single recompile!
This Feather is also a BLE-friendly CircuitPython board! CircuitPython works best with disk drive access, and this is the only BLE-plus-USB-native chip that has the memory to handle running a little Python interpreter. The massive RAM and speedy Cortex M4F chip make this a good match. Make centrals or peripherals with the ease of CircuitPython.
A chorus of supporting sensors surround the module so you can do all sorts of environmental and motion-sensing:
- ST Micro series 9-DoF motion – LSM6DS33 Accel/Gyro + LIS3MDL magnetometer
- APDS9960 Proximity, Light, Color, and Gesture Sensor
- PDM Microphone sound sensor
- SHT Humidity
- BMP280 temperature and barometric pressure/altitude
Features:
- ARM Cortex M4F (with HW floating point acceleration) running at 64MHz
- 1MB flash and 256KB SRAM
- Native Open Source USB stack – pre-programmed with UF2 bootloader
- Bluetooth Low Energy compatible 2.4GHz radio
- FCC / IC / TELEC certified module
- Up to +8dBm output power
- 21 GPIO, 6 x 12-bit ADC pins, up to 12 PWM outputs (3 PWM modules with 4 outputs each)
- Pin #13 red LED for general purpose blinking, Blue LED for general purpose connection status, NeoPixel for colorful feedback
- Power/enable pin
- Reset button
- SWD debug pads on the bottom of the PCB
Package Includes:
1 x Adafruit Feather nRF52840 Sense
Datasheet:-
https://share.google/cjZwjhn5T7TVcEQJK
Adafruit Feather nRF52840 Sense Overview
The Adafruit Feather nRF52840 Sense is a compact ARM Cortex-M4F development board with a built-in Bluetooth Low Energy radio and onboard USB support. Designed for wireless sensing projects, it combines a powerful microcontroller with an array of integrated sensors to capture environmental and motion data in real time.
Key Features of Adafruit Feather nRF52840 Sense
- ARM Cortex M4F processor @64 MHz with hardware floating-point acceleration
- 1 MB onboard flash memory and 256 KB SRAM for complex applications
- Native USB with UF2 bootloader for drag-and-drop programming and CircuitPython compatibility
- Bluetooth Low Energy 2.4 GHz radio, FCC/IC/TELEC certified for global use
- Integrated LiPo battery charging circuit and JST connector for portable projects
- Onboard multi-sensor suite for environmental (temperature, humidity, pressure) and motion data
- Fast shipping from Zbotic across India with genuine Adafruit modules
Applications and Use Cases
- Wireless environmental monitoring stations for temperature and humidity logging
- Wearable motion trackers and gesture-controlled interfaces
- IoT sensor nodes for smart home and industrial automation
- Portable prototype devices powered by LiPo batteries
- BLE beacons and remote control peripherals
- Rapid development with CircuitPython or Arduino IDE
How to Use Adafruit Feather nRF52840 Sense
Connect the Feather nRF52840 Sense to your computer via USB and enter bootloader mode by pressing the reset button twice. Drag the UF2 bootloader file onto the virtual drive to enable native USB programming, then write code in Arduino IDE or CircuitPython and deploy via the USB interface. Attach a LiPo battery for standalone operation and access sensor data through your chosen firmware.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What sensors are built into the Feather nRF52840 Sense?
This board includes a multi-sensor array capable of measuring temperature, humidity and barometric pressure, plus motion sensing for acceleration and orientation—all onboard without extra modules.
Can I program the Feather Sense with CircuitPython?
Yes, the native USB interface and UF2 bootloader make it straightforward to load CircuitPython firmware. Just copy the .UF2 file to the board and edit your Python scripts directly.
How do I enable Bluetooth Low Energy on this board?
Install the Nordic SoftDevice BLE stack via Arduino IDE or include appropriate libraries in CircuitPython. Once loaded, use the Adafruit BLE libraries to advertise and connect from any BLE-compatible device.
Technical Specifications
| Brand | Adafruit |
|---|---|
| SKU | AI1759 |
| Weight | 0.01 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Adafruit Feather nRF52840 Sense is a versatile arm microcontroller used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
