41F Hall
The model 41F (also known by part numbers TO-92S, 0H41, SH41, SS41F, and S41) is a versatile component designed for use in electric vehicles and industrial motors. It operates within a voltage range of 4.5V to 24V and provides an output current of 25mA, making it compatible with most open-collector systems.
With an operating temperature range of -40°C to +150°C, this part is built to withstand harsh conditions. It features 3-pin terminals, with a pin length of approximately 15mm (0.59 inches). This component is also ideal for use in the repair of brushless motors in electric bikes or scooters.
Specification:
| Specification | Value/Description |
|---|---|
| Type | Switched Hall-effect IC |
| Operating Voltage Range | Typically around 4.5V to 24V |
| Hall Voltage Generator | On-chip |
| Amplifier | Included on-chip |
| Schmitt Trigger | Included on-chip |
| Output | Open-collector output |
| Output Current | Typically low, compatible with various loads |
| Switching Hysteresis | Provided by the Schmitt trigger for noise rejection |
| Sensing Method | Contactless magnetic sensing |
| Applications | Contactless switching applications |
| Temperature Range | Typically specified by the manufacturer (e.g., -40°C to 125°C) |
| Package | Various packages available, such as SOT-23, TO-92, or similar |
PACKAGE INCLUDES:
1 X 41F Hall
