100K Ohm 0.25W Carbon Film Resistor (Pack of 100)

100K Ohm 0.25W Carbon Film Resistor

A carbon film resistor is a type of fixed resistor that utilizes a carbon film to limit electric current to a specific level. These resistors are commonly used in electronic circuits.

The 100K Ohm 0.25W Carbon Film Resistor is an essential electronic component widely employed in various circuits for tasks such as voltage division, current limiting, and signal conditioning. With a resistance value of 100K Ohms (100,000 Ohms), it provides significant resistance to electric current, making it suitable for a diverse range of applications.

With a power rating of 0.25 Watts, this resistor can reliably handle power dissipation while generating minimal heat. Its construction features a carbon film on a ceramic substrate, offering stability, precision, and low noise characteristics to ensure consistent performance in different environmental conditions.

Packaged in sets of 100, these resistors offer a convenient and economical solution for projects that require multiple units. They are widely used in various electronic devices and circuits, including LED circuits, audio amplifiers, voltage dividers, and sensor interfaces.

Their compact size and axial lead design facilitate easy integration into breadboards, printed circuit boards (PCBs), and for through-hole soldering. Overall, the 100K Ohm 0.25W Carbon Film Resistor delivers reliable performance and precise resistance values, making it an essential component for many electronic projects and applications.

Features

Carbon Film Resistor

High Quality

Specification:

Product Code=CFR-W25-100K

100K ohm 1/4-watt high quality CFR

Tolerance: ±5%

Tin Plated Copper Leads.

Color Code: Brown, Black, Yellow, Golden

Package Includes

100 x 100K Ohm 0.25W Carbon Film Resistor

100K Ohm 0.25W Carbon Film Resistor Overview

The 100K Ohm 0.25W Carbon Film Resistor is a fixed-value resistor featuring a carbon film on a ceramic core, designed to limit current in electronic circuits. With a resistance of 100,000 Ω and a power rating of 0.25 W, it’s ideal for precision tasks like voltage division and signal conditioning.

Key Features of 100K Ohm 0.25W Carbon Film Resistor

• Resistance: 100K Ohm (100,000 Ω) with ±5% tolerance for reliable circuit performance
• Power Rating: 0.25 W carbon film design offers stable operation with minimal heat
• Construction: Carbon film deposited on ceramic substrate for consistent resistance over time
• Leads: Tin-plated copper leads ensure easy soldering and corrosion resistance
• Color Code: Brown-Black-Yellow-Golden stripes for quick value identification
• Pack Quantity: 100 pieces per pack, ideal for bulk projects and prototyping
• Fast Shipping: Ships quickly from Zbotic’s Indian warehouse for prompt delivery

Applications and Use Cases

• Voltage divider networks in analog and digital circuits
• Biasing transistors and setting input impedance in amplifier stages
• Pull-up or pull-down resistor in microcontroller GPIO interfaces
• RC timing circuits for oscillators and filter networks
• Signal conditioning in sensor modules and data acquisition systems
• Leakage current limiter in high-voltage measurement setups

How to Use 100K Ohm 0.25W Carbon Film Resistor

Identify the resistor by its Brown-Black-Yellow-Golden color bands, then insert the tin-plated leads through your PCB or perfboard holes. Position it according to your schematic, solder each lead to the copper pad, and trim excess lead length. Ensure the resistor’s power dissipation stays within 0.25 W by verifying voltage and current levels in your design.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

What is the voltage limit for a 100K 0.25W resistor?

With a 0.25 W rating and 100K Ω resistance, the maximum continuous voltage is approximately 158 V (V = √(P×R)), assuming proper cooling and ambient conditions.

How do I read the color code Brown-Black-Yellow-Golden?

The first band “Brown” is 1, second “Black” is 0, the third “Yellow” is multiplier 10^4, giving 10 × 10^4 Ω = 100,000 Ω, and the “Golden” band indicates ±5% tolerance.

Can I use these resistors for high-precision circuits?

These carbon film resistors offer ±5% tolerance, suitable for general-purpose applications. For higher precision, consider metal film resistors with tighter tolerance.
