YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal(Pack of 2)

YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal

Introducing the YXC HC-49SMD Quartz Crystal, meticulously crafted to enhance the performance of your electronic projects. With a frequency of 16.384MHz, this crystal delivers precision timing, making it perfect for a myriad of applications, from microcontrollers to communication systems.

Featuring a load capacitance of 20pF and a frequency tolerance of ±20PPM, this crystal ensures stable and accurate operation even in demanding conditions. Its SMD/SMT package allows for easy integration onto PCBs, simplifying your assembly process.

Trust in the reliability and quality of YXC products. Upgrade your electronic designs with the YXC HC-49SMD Quartz Crystal and experience enhanced performance and stability.

Features:

1. Frequency: Operating at a precise frequency of 16.384MHz, this crystal provides accurate timing for various electronic applications.
2. Load Capacitance: With a load capacitance of 20pF, it ensures optimal performance and stability in your circuits.
3. Frequency Tolerance: The crystal has a frequency tolerance of ±20PPM (Parts Per Million), ensuring consistent and reliable operation over a wide range of conditions.
4. Package/Mounting Type: Designed for Surface Mount Technology (SMD/SMT), this crystal is easy to mount on PCBs, streamlining the manufacturing process.
5. Number of Pads: Equipped with 2 pads, facilitating secure and stable connections during assembly.
6. RoHS Compliance: This crystal adheres to RoHS (Restriction of Hazardous Substances) regulations, ensuring environmental friendliness and safety.
7. Manufacturer: Produced by YXC, a reputable manufacturer known for high-quality electronic components, ensuring reliability and performance.

Specifications:

Package Includes

• 1 x YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal(Pack of 2)

YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Overview

The YXC HC-49SMD is a surface-mount quartz crystal oscillating at 16.384 MHz, designed to provide precise timing for electronic circuits. Ideal for microcontrollers, communication modules, and digital systems, it offers stable frequency performance in a compact SMD/SMT form factor.

Key Features of YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz

• Frequency: 16.384 MHz for accurate clock generation
• Load Capacitance: 20 pF to match common oscillator circuits
• Frequency Tolerance: ±20 PPM ensures minimal drift
• SMD/SMT Package: Two-pad configuration for easy PCB integration
• Pack of 2: Includes two identical crystals for redundancy or dual designs
• Genuine Product & Fast Shipping from Zbotic

Applications and Use Cases

• Clock source for microcontroller and FPGA-based boards
• Timing reference in communication modules (UART, SPI, I²C)
• Frequency standard for digital signal processors
• Stabilization component in RF transceiver front-ends
• Timebase for real-time clock and timer circuits
• Precision oscillator in embedded sensor networks

How to Use YXC – HC-49SMD 16.384MHZ 20PF 20PPM 2Pad SMD/SMT Quartz

Place the HC-49SMD crystal on your PCB’s two-pad SMD footprint according to the manufacturer’s recommended land pattern. Solder using a standard reflow profile compatible with 20 pF load crystals. Position the part close to the oscillator input pins of your microcontroller or oscillator IC for optimal performance.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

What does “20 PPM tolerance” mean for this crystal?

±20 PPM indicates the maximum frequency deviation of 20 parts per million at 25 °C. It ensures that the oscillator stays within 16.384 MHz ±0.3277 kHz under specified conditions.

How do I choose the PCB footprint for an HC-49SMD?

Use a two-pad SMD land pattern matching the crystal’s pad spacing. Refer to the HC-49SMD datasheet for exact pad dimensions and keep the pads as close as possible to your oscillator IC pins.

Can this 16.384 MHz crystal be used with a real-time clock module?

Yes. Many RTC and timer circuits accept 16.384 MHz inputs, allowing you to derive lower-frequency clocks (e.g., 32.768 kHz) by dividing down the high-frequency signal.
