Product Description
The WCS1700 current sensor is an economical and precise solution for DC and AC current sensing in various systems, such as industrial, commercial, and communications systems.
The sensor has a unique package that allows easy implementation without altering the original system. It enables current sensing by letting the system’s own electric wire pass through a 9.0mm diameter hole. Typical applications include motor control, load detection and management, over-current fault detection, and any intelligent power management system, etc.
The WCS1700 has a linear hall sensor IC with low-temperature drift and a temperature compensation circuit. The sensor IC detects the magnetic field generated by any current passing through the hole and converts it into a proportional voltage.
Features:
- The current detection resolution of 32mV / A
- Output overcurrent signal indication
- Overcurrent signal is set critical point adjustable settings Resolution 3A
- With mounting holes for easy firmware installation
- Sampling current converting analog signal output, which can be accessed ADC, TTL level signal output, which can be accessed microcontroller IO port control.
- The output signal is the signal level of the analog signal.
- Maximum current sensing range : 70A
Note : Color may be different .
Package Includes:
1 x WCS1700 Hall Current Sensor with Over Current Protection
Datasheet:
MLX90640 Thermal Camera Array: Build a Fever Scanner
Table of ContentsIntroduction to the MLX90640How Thermal Array Sensors WorkMLX90640 SpecificationsHardware RequirementsWiring to Arduino / ESP32Library Installation and...
Read More →
PIR Motion Sensor: How It Works + Arduino Project
A PIR sensor (Passive Infrared Sensor) is one of the most popular components in electronics for motion detection....
Read More →
Gyroscope Sensor Guide: How It Works & Best Modules for Drones
A gyroscope sensor is the electronic heart of every modern drone, stabilized camera gimbal, self-balancing robot, and flight...
Read More →Technical Specifications
| Model | WCS1700 |
|---|---|
| SKU | AI2658 |
| Weight | 0.02 kg |
| Availability | Out of Stock |
Applications & Use Cases
The WCS1700 Hall Current Sensor with Over Current Protection is a versatile current and voltage sensor used across a wide range of applications including power monitoring, energy metering, battery management, solar panel monitoring, and industrial current sensing.
Common use cases:
- Monitoring power consumption of appliances
- Building a solar panel efficiency tracker
- Current sensing in a battery management system
This product is ideal for power electronics engineers and IoT developers.
Technical Tip: Hall-effect sensors are non-invasive (no wire cutting needed). Shunt-based sensors offer higher accuracy. Match the sensor range to your application.
