Description:
Onboard power and signal isolation, provide stable isolated voltage, high reliability and strong anti-interference. Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, anti-electrostatic. Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provides over-current/over-voltage protection, improves shock resistance.
TTL TO RS422 (B) is an industrial-grade rail-mounted electrically isolated TTL-to-RS485 serial converter.
Features:
-
Compatible with TTL/RS422 standard, converting the TTL signal into differential RS422 signal, support full duplex communication
-
Compatible with 3.3V ~ 5V TTL signal level, provides anti-reverse and over-voltage protection for power supply interface
-
Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal
-
Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
-
Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, anti-electrostatic
-
Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage protection, improve shock resistance
-
Onboard RS422 input and output terminal 120R resistor, enabled/disabled via jumper
-
Case: Rail-mount ABS case, suitable for 35mm DIN rail
-
Transmission Mode: full duplex mode, point-to-multipoint (up to 256 nodes, it is recommended to use repeaters for 16 nodes or more)
Package Includes:
-
1 x Waveshare Rail-mount TTL To RS422 Galvanic isolated Converter, Anti-surge, Multiple Isolation Protection.
Technical Specifications
| Brand | WAVESHARE |
|---|---|
| Interface / Protocol | TTL |
| SKU | AI7669 |
| Weight | 0.14 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Waveshare Rail-mount TTL To RS422 Galvanic isolated Converter, Anti-surge, Multiple Isolation Protection is a versatile usb interface module used across a wide range of applications including serial communication, industrial automation, data logging, PLC interfacing, and IoT gateway.
Common use cases:
- Converting USB to RS485 for industrial equipment
- Building a data logger for factory sensors
- Debugging embedded systems via UART
This product is ideal for embedded system developers and industrial automation engineers.
Technical Tip: Industrial-grade modules with isolation protect against ground loops and voltage spikes in noisy environments.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
- Genuine WAVESHARE product sourced from authorized channels
