RGB 5050 12V LED Board 7 Colors with DIP Switch
This is RGB 5050 12V LED Board 7 Colors with DIP Switch. The RGB LED Board 5050 12V is designed for the Multi-rotors & FPV Quad-rotors with BEC power or any other 11-13V power source. It comes with three RGB5050 LEDs & one code switch.
Seven colors are selectable using the code switches. This LED board gives an eye-catching effect to your multi-rotors or planes.
Selectable Colours & Power
Package Includes :
1 x RGB 5050 12V LED Board.
1 x Cable 30 cm.
RGB 5050 12V LED Board 7 Colors with DIP Switch Overview
The RGB 5050 12V LED Board 7 Colors with DIP Switch is a compact lighting module featuring three SMD 5050 LEDs and an onboard DIP switch for selecting seven distinct colors. Designed for 11–13V DC systems—such as 12V BEC outputs on multi-rotor aircraft—it adds vibrant, attention-grabbing illumination to drones, planes, and custom electronics projects.
Key Features of RGB 5050 12V LED Board 7 Colors with DIP Switch
- Seven selectable colors (Red, Green, Blue, Purple, Cyan, Yellow, White) via a simple 3-position DIP switch
- Operates on any 11–13V DC supply (ideal for 12V BEC on FPV quadcopters)
- Low current draw: 30mA per color channel, up to 90mA when all three are ON
- Compact 47×10 mm PCB footprint weighing only 5 g for minimal added mass
- Easy integration into multi-rotor frames, RC planes, robotics projects, and lighting strips
- Genuine product with fast shipping from Zbotic across India
Applications and Use Cases
- Orientation lights on FPV quadcopters and hexacopters
- Position indicators for RC planes and helicopters
- Status or notification lamp on custom robotics and embedded electronics
- Accent lighting in model cars, boats, and RC tanks
- Decorative backlighting for instrument panels or control stations
- Portable LED markers for field testing and prototyping
How to Use RGB 5050 12V LED Board 7 Colors with DIP Switch
Connect the board’s positive (+) and ground (–) pads to an 11–13V DC source, such as a 12V BEC output. Use the three-position DIP switch to toggle each R, G, and B channel on or off—combining switches yields your desired color. Secure the board with adhesive tape or nylon standoffs and ensure wiring is insulated for vibration-free operation.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How do I select different colors?
Use the three-position DIP switch to enable each R, G, B LED channel. Turning on individual or combined channels yields the seven available colors without any soldering or programming.
What power supply does this board require?
It runs on 11–13V DC (12V BEC recommended). Each color channel draws 0.03 A, so allow up to 0.09 A from your power source if all three channels are active.
Can I install this on my FPV quadcopter frame?
Yes. The 47×10 mm PCB is lightweight (5 g) and fits easily on drone arms or under canopies. Secure it with double-sided tape or nylon standoffs near your BEC output for reliable illumination.
