This is the 330mm variant of the Martian IV 8'' 330mm Quadcopter Frame in Drone Frame and Accessories. Available at ₹2,491.65 (₹2,373.00 + GST) with free shipping across India.
Martian IV 8 330mm carbon frame for assembling a quadcopter on 8-inch propellers.
Frame size on motor axes: 330mm
Beam thickness: 4mm
Top & Side Plates: 2mm
Front Bottom Plate: 2mm
Back Bottom Plate: 1.5mm
Stack mounting holes: 30.5 x 30.5mm
Mounting holes for motors: M3, 16 x 19mm
Weight: 169g
Package Include :
1 x Martian IV 8” 330mm Quadcopter Frame
Martian IV 8” 330mm Quadcopter Frame Overview
The Martian IV 8” 330mm Quadcopter Frame is a precision-engineered carbon fiber chassis designed to build a custom quadcopter around 8-inch propellers. With a 330 mm motor-to-motor layout and reinforced plate layers, it offers a lightweight yet rigid platform for FPV racing, freestyle flying, or aerial photography rigs.
Key Features of Martian IV 8” 330mm Quadcopter Frame
- Carbon fiber construction with 4 mm thick arms for high strength-to-weight ratio
- 330 mm diagonal motor spacing optimized for 8″ propeller clearance
- 30.5 × 30.5 mm stack mounting pattern accommodates most flight controller boards
- M3 motor mounting holes (16 × 19 mm) fit a wide range of brushless motors
- Overall frame weight of just 169 g enhances agility and extends flight time
- Genuine product with fast shipping from Zbotic
Applications and Use Cases
- FPV racing builds requiring a stiff, lightweight chassis for 8″ props
- Freestyle quads for dynamic indoor and outdoor maneuvers
- Lightweight aerial photography platforms carrying compact cameras
- STEM education and research projects exploring drone dynamics
- Prototype development of autonomous flight systems
- Upgrading existing frames to a more durable carbon fiber design
How to Use Martian IV 8” 330mm Quadcopter Frame
Begin by attaching the carbon arms to the front and back bottom plates, then secure the flight controller stack onto the 30.5 × 30.5 mm posts. Mount your brushless motors using M3 screws in the 16 × 19 mm holes, add the top and side plates for rigidity, and tighten all hardware to the recommended torque. Finally, install your 8″ propellers, perform a motor spin test, and adjust as needed before maiden flight.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What propeller size is supported by the Martian IV frame?
The Martian IV 8” 330 mm frame is specifically designed for 8-inch propellers, offering optimal clearance and thrust balance without interference.
Which flight controller stack fits this frame?
This frame features a 30.5 × 30.5 mm mounting pattern, compatible with most standard flight controller and ESC stacks available on the market.
How does the 169 g frame weight impact flight performance?
At just 169 g, the frame adds minimal mass to your build, improving the thrust-to-weight ratio and extending battery life for longer flight times and sharper responsiveness.
Drone Build Troubleshooting: Common First-Build Mistakes
Every drone builder faces setbacks during their first build, and effective drone build troubleshooting is a skill that...
Read More →
Tethered Drone Build: Unlimited Flight Time for Events and Surveillance
Tethered Drone Build: Unlimited Flight Time for Events and Surveillance Imagine a drone that can hover for eight...
Read More →
VTOL Drone Build: Tilt-Rotor Transition from Hover to Flight
VTOL Drone Build: Tilt-Rotor Transition from Hover to Flight VTOL (Vertical Take-Off and Landing) drones represent the perfect...
Read More →Technical Specifications
| Size | 330mm |
|---|---|
| SKU | AI4428 |
| Weight | 0.2717 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Martian IV 8'' 330mm Quadcopter Frame is a versatile drone frame and accessories used across a wide range of applications including FPV racing builds, freestyle drones, cinematic drones, and agricultural spraying platforms.
Common use cases:
- Building a new racing quad
- Replacing a broken frame arm after a crash
- Mounting a camera gimbal on a custom platform
This product is ideal for FPV builders, drone racing enthusiasts, and commercial drone operators.
Technical Tip: Carbon fiber frames offer the best strength-to-weight ratio. Ensure motor-to-motor distance matches your propeller size.
