This is the 54mm variant of the Male Dupont Terminal Reed Connector 2.54mm-5 Pins in FFC, FPC, Berg connectors. Available at ₹19.59 (₹16.60 + GST) with free shipping across India.
Product Description
This is a male reed connector with DuPont terminal crimps. It has a 2.54mm pitch and can plug into female DuPont connectors of the same size.
Specifications and Features:
- Pin pitch: 2.54mm
- Temperature range: -25 ~ 85 ℃
- Maximum current: 1A
- Maximum voltage: 250V AC/DC
- Compatible Wire Gauge (AWG): 28-22
- Withstanding voltage: 800V AC/1 min
Package Includes:
1 x Male Dupont Terminal Reed Connector 2.54mm-5 Pins
Male Dupont Terminal Reed Connector 2.54mm-5 Pins Overview
The Male Dupont Terminal Reed Connector 2.54mm-5 Pins is a five-position plug housing designed for reliable wire-to-board connections. With a standard 2.54mm pitch and compatible with female DuPont headers, it’s ideal for creating custom jumper cables and interconnects in electronics projects.
Key Features of Male Dupont Terminal Reed Connector 2.54mm-5 Pins
- Standard 2.54mm pitch, 5-pin inline connector
- Maximum current rating of 1A and voltage up to 250V AC/DC
- Wide temperature range from -25℃ to +85℃ for varied environments
- Compatible with AWG 28–22 wires for flexible use
- Withstanding voltage of 800V AC for one minute ensures safety
- Fast shipping from Zbotic for quick project turnaround
Applications and Use Cases
- Breadboard and prototype jumper wire assemblies
- Robotics sensor and actuator cable harnesses
- Microcontroller I/O extension and breadboarding
- Repair and replacement of damaged DuPont-style connectors
- DIY electronics kits and educational lab work
- Custom cable assemblies for industrial control panels
How to Use Male Dupont Terminal Reed Connector 2.54mm-5 Pins
Strip approximately 3–5 mm of insulation from your AWG 28–22 wire, insert the bare conductor fully into the metal reed terminal, then crimp securely using a precision crimping tool. Slide each terminal into the plastic housing until it clicks. Finally, plug the assembled connector into a matching 2.54 mm female DuPont header, ensuring correct pin alignment.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What wire gauge is compatible with this connector?
This connector supports AWG 28–22 wires, allowing for flexible use with thin jumper wires and slightly thicker signal leads.
Can I use these connectors for high-voltage projects?
They are rated for up to 250V AC/DC continuous voltage and withstand 800V AC for one minute under test conditions, suitable for most low- to medium-voltage applications.
How do I crimp the male Dupont terminal onto a wire?
Strip 3–5 mm of insulation, insert the wire into the terminal’s barrel, use a dedicated Dupont crimping tool to secure both insulation and conductor wings, then verify the crimp pull strength before housing insertion.
Technical Specifications
| Size | 2.54mm |
|---|---|
| SKU | AI2814 |
| Weight | 0.00026 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Male Dupont Terminal Reed Connector 2.54mm-5 Pins is a versatile ffc, fpc, berg connectors used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
