Looking for Kp Original 802540 Battery? KP Original 802540 1200mAh 3.7Vsingle cell Rechargeable LiPo Battery is available at Zbotic with fast shipping across India.
Description:
Introducing the 802540 1200mAh 3.7Vsingle cell Rechargeable LiPo Battery, designed for compact electronic devices requiring reliable power in a small form factor. With its high energy density and lightweight design, this battery is ideal for applications in drones, remote controls, wearables, and other portable electronics.
Features:
- Overcharge Protection: Yes
- Over-discharge Protection: Yes
- Short Circuit Protection: Yes
- Fire Resistance: LiPo batteries are generally housed in protective casings to prevent fire hazards.
Specifications:
- Model Number: 802540
- Type: Lithium Polymer (LiPo)
- Nominal Voltage: 3.7V
- Capacity: 1200 mAh
- Discharge Rate: 1C (1200 mA continuous current)
- Charge Voltage: 4.2V (maximum)
- Discharge Cut-off Voltage: 3.0V (minimum)
- Dimensions: 41mm x 25 mm x 8.0 mm
- Temperature Range for Charging: 0°C to 45°C
- Temperature Range for Discharging: -20°C to 60°C
- Cycle Life: Typically, 300-500 cycles at standard charge/discharge rates
- Self-Discharge Rate: Approximately 3-5% per month
- Charging Method: Constant current / constant voltage (CC/CV)
- Recommended Charge Current: 0.5C to 1C (600 mA – 1200 mA)
- Charge Time: Approximately 1.5 to 3 hours, depending on charge current.
Applications:
- Remote control devices
- Drones and UAVs
- Mobile devices and electronics
- Wearable technology
Package Includes:
- 1xKP Original 802540 1200mAh 3.7Vsingle cell Rechargeable LiPo Battery
KP Original 802540 1200mAh 3.7Vsingle cell Rechargeable Overview
The KP Original 802540 is a high-energy 3.7V single cell LiPo battery with a 1200mAh capacity, designed for compact electronic devices. Its slim 41×25×8 mm profile and lightweight construction make it ideal for drones, wearables, remote controls and other portable gadgets.
Key Features of KP Original 802540 1200mAh 3.7Vsingle cell Rechargeable
- 1200 mAh capacity at 3.7 V nominal voltage for stable, long-lasting power
- Compact 41 × 25 × 8 mm size fits into micro drones and small enclosures
- Built-in overcharge, over-discharge and short-circuit protection for enhanced safety
- Fire-resistant casing reduces risk of thermal incidents during use
- Genuine KP Original battery sourced from authorized distributors
- Fast shipping across India from Zbotic within 24 hours
Applications and Use Cases
- Powering micro and nano drones for extended flight times
- Driving RC cars, helicopters and gliders with limited battery compartments
- Supplying energy to wearable fitness trackers and smart textiles
- Running DIY robotics and electronics projects in confined spaces
- Operating portable audio recorders and mini communication modules
How to Use KP Original 802540 1200mAh 3.7Vsingle cell Rechargeable
Use a dedicated LiPo charger set to 3.7 V and 1.2 A (1C) charging rate, connect red (+) and black (–) leads correctly, and monitor until fully charged. Insert the battery into your device’s battery bay, ensuring connectors are secure and wires aren’t pinched. After use, store at about 50% charge in a cool, dry place to maintain longevity.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum continuous discharge current of this battery?
The KP 802540 supports a continuous discharge rate of 1C (1,200 mA), suitable for moderate-draw applications in small devices.
Does the battery include built-in protection circuits?
Yes, it features integrated overcharge, over-discharge and short-circuit protection to ensure safe operation during charging and use.
Can I connect multiple cells in series for higher voltage packs?
This product is sold as a single cell unit. For series configurations you must use matched cells and a proper balance charger to maintain safety and performance.
Power Path Controller: Charge and Use Battery Simultaneously
A power path controller allows your device to simultaneously charge a battery and power the system from an...
Read More →
Power Supply for Arduino: Best Options Compared (USB, 9V, DC)
Choosing the right power supply for Arduino options is one of the most fundamental decisions you will make...
Read More →
Solar Panel IV Curve: Understanding Open Circuit Voltage
Solar Panel IV Curve: Understanding Open Circuit Voltage If you have ever picked up a solar panel for...
Read More →Technical Specifications
| Brand | KP |
|---|---|
| Battery Capacity | 1200mAh |
| Interface / Protocol | BLE |
| SKU | AI6766 |
| Weight | 0.02 kg |
| Availability | In Stock |
Applications & Use Cases
The KP Original 802540 1200mAh 3.7Vsingle cell Rechargeable LiPo Battery is a versatile single cell micro lipo battery used across a wide range of applications including FPV drones, RC vehicles, portable electronics, robotics, and airsoft guns.
Common use cases:
- Powering an FPV racing drone
- Running a high-current RC car
- Portable power for field robotics
This product is ideal for drone pilots, RC enthusiasts, and robotics builders.
Technical Tip: Never discharge below 3.5V per cell. Store at 3.8V per cell. Always use a balance charger and never leave charging unattended. Use a LiPo bag for safety.
