Description:
The Pixhawk® 6C Mini is the latest update to the successful family of Pixhawk® flight controllers, based on the Pixhawk® FMUv6C Open Standard and Connector Standard. It shares the same STMH743 microprocessor and sensors as the Pixhawk® 6C. Compared to the standard Pixhawk® 6C, this Mini version has a built-in PWM header, and some ports have been removed to fit this Mini form factor.
Inside the Pixhawk® 6C Mini, you can find an STMicroelectronics®-based STM32H743, paired with sensor technology from Bosch® & InvenSense®, giving you flexibility and reliability for controlling any autonomous vehicle, suitable for both academic and commercial applications.
The Pixhawk® 6C Mini’s H7 microcontroller contains the Arm® Cortex®-M7 core running up to 480 MHz and has 2MB flash memory and 1MB RAM. Thanks to the updated processing power, developers can be more productive and efficient with their development work, allowing for complex algorithms and models.
The FMUv6C open standard includes high-performance, low-noise IMUs on board, designed to be cost-effective while having IMU redundancy. A vibration isolation system to filter out high-frequency vibration and reduce noise to ensure accurate readings, allowing vehicles to reach better overall flight performances.
The Pixhawk® 6C Mini is perfect for developers at corporate research labs, startups, academics (research, professors, students), and commercial applications.
Key Design Points
- High performance STM32H743 Processor with more computing power & RAM
- New cost-effective design in a small form factor
- IMU redundancy with sensor technology from Bosch® & InvenSense®
- Integrated vibration isolation system to filter out high frequency vibration and reduce noise to ensure accurate readings
- IMUs are temperature-controlled by onboard heating resistors, allowing optimum working temperature of IMUs
- Hardware switchable 3.3V or 5V PWM signal mode (requires opening the casing)
Specification
Processors & Sensors
- FMU Processor: STM32H743
- 32 Bit Arm® Cortex®-M7, 480MHz, 2MB memory, 1MB SRAM
- IO Processor: STM32F103
- 32 Bit Arm® Cortex®-M3, 72MHz, 64KB SRAM
- On-board sensors
- Accel/Gyro: ICM-42688-P
- Accel/Gyro: BMI088 (BMI055 discontinued due to the end of production of the sensor)
- Mag: IST8310
- Barometer: MS5611
Electrical data
- Voltage Ratings:
- Max input voltage: 6V
- USB Power Input: 4.75~5.25V
- Servo Rail Input: 0~36V
- The new version Model A now provides a more stable PWM signal when underload
- Current Ratings:
- Telem1 & GPS2 combined current limit: 1.5A
- All other ports combined current limit: 1.5A
- Operating temperature: -40 ~ 85°c
Mechanical data
- Dimensions (Model A Legacy): 53.3 * 39 * 16.2 mm
- Dimensions (Model A Current): 54.3x39x17.5 mm
- Dimensions (Model B): 58.3x39x18.15 mm
- Weight (Model A Legacy): 39.2g
- Weight (Model A Current): 42.4g
- Weight (Model B): 46.8g
Reference Link
- Ports and Pinout
- Dimension
- Supported Firmware
- Pixhawk 6C & 6C Mini Difference
- System Diagram & Pinout
Build a Drone LiDAR Terrain Mapper with ArduPilot & ROS: Step-by-Step Project Guide
LiDAR (Light Detection and Ranging) technology has rapidly moved from the domain of military satellites and expensive survey...
Read More →
LiPo Battery Care: Charging, Storage, and Safety
Table of Contents Understanding LiPo Battery Care Key Components and Requirements Step-by-Step Setup Guide Configuration and Optimisation Practical...
Read More →
Agriculture Sprayer Drone: Complete Guide to Tank, Pump and Nozzle Selection
Table of ContentsWhy Agriculture Sprayer Drones Are Transforming Indian FarmingSprayer System Components OverviewTank Selection: Capacity, Material, and MountingPump...
Read More →Technical Specifications
| Brand | Holybro |
|---|---|
| Discharge Rate | 6C |
| SKU | AI7862 |
| Weight | 0.3575 kg |
| Availability | In Stock |
Applications & Use Cases
The Holybro Pixhawk 6C Mini Mode-A Flight controller is a versatile flight controller & accessories used across a wide range of applications including autonomous drones, FPV racing quadcopters, agricultural drones, and surveying and mapping platforms.
Common use cases:
- Central brain for drone stabilization and navigation
- GPS waypoint missions for surveying
- Acro mode flying for FPV freestyle
This product is ideal for drone builders requiring precise flight control.
Technical Tip: F4 processors are good for basic builds; F7 or H7 recommended for advanced features. Ensure firmware compatibility (Betaflight, ArduPilot, iNAV).
