Looking for Dry Reed Pipe Module? Dry Reed Pipe Magnetron Magnetic switch Module is available at Zbotic with fast shipping across India.
Dry Reed Pipe Module – Description:
This module finds versatile applications in program-controlled switches, copiers, washing machines, refrigerators, cameras, disinfection cabinets, magnetic door and window sensors, electromagnetic relays, electronic weighing scales, level meters, gas meters, water meters, and various other devices and systems.
Specifications:
| Item Type | Electronic Switch |
|---|---|
| Operating Voltage (VDC) | 3.3 to 5 |
| Detecting Range | 1.5m |
| Length (mm) | 44 |
| Width (mm) | 17 |
| Height (mm) | 13 |
Features:
- Clean, good waveform driving ability, more than 15mA.
- Working voltage: 3.3V – 5V
- Output format: Digital switching output (0 and 1)
- A fixed bolt holes for easy installation
- PCB size: 3.2cm x 1.4cm
- Using a wide voltage LM393 comparator
Package Includes:
-
1 x Dry Reed Pipe Magnetron Magnetic Switch Module
Dry Reed Pipe Magnetron Magnetic switch Module Overview
The Dry Reed Pipe Magnetron Magnetic switch Module is a compact magnetic proximity switch that outputs a clean digital signal when exposed to a magnetic field. Designed for reliable on/off detection, it is ideal for embedding into control panels, safety interlocks and automated systems.
Key Features of Dry Reed Pipe Magnetron Magnetic switch Module
- Operating Voltage: 3.3 V to 5 V DC compatibility
- Digital Output: Clean on/off switching signal (0 and 1)
- Driving Ability: Stable waveform with over 15 mA current drive
- Detection Range: Up to 1.5 meters with suitable permanent magnets
- Mounting Holes: Fixed bolt holes for secure attachment
- Compact Footprint: 44 × 17 × 13 mm module size
- Fast Shipping: Genuine modules dispatched quickly from Zbotic
Applications and Use Cases
- Magnetic door and window sensors in security systems
- Position detection for washing machines, copiers and cameras
- Level monitoring in water meters, gas meters and level gauges
- Activation of electromagnetic relays and solenoids
- Limit switching in 3D printers and CNC machines
- Safety interlocks for refrigeration and disinfection cabinets
How to Use Dry Reed Pipe Magnetron Magnetic switch Module
Mount the module using its fixed bolt holes on a stable surface near the moving magnet. Wire the module’s VCC to a 3.3 V–5 V supply and GND to ground. Read the digital OUT pin with your microcontroller or logic circuit to detect when the magnetic field closes the reed switch.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the operating voltage range?
This magnetic switch module operates from 3.3 V up to 5 V DC, making it compatible with most microcontroller platforms.
What detection range can I expect?
The module can detect a permanent magnet from distances up to 1.5 meters, though for consistent switching we recommend positioning within 0.5 meters.
How do I mount and wire the module?
Secure the module using its fixed bolt holes. Connect the VCC pin to a 3.3 V–5 V supply, GND to ground, and monitor the digital OUT pin on your controller for high/low signals when a magnet approaches.
