Description:
The DHT20 is an upgraded version of the DHT11, featuring a dedicated ASIC sensor chip, a high-performance semiconductor silicon-based capacitive humidity sensor, and an integrated on-chip temperature sensor. It uses a standard I2C data output format for easy integration.
With significant improvements in performance, the DHT20 surpasses the reliability and accuracy of its predecessor. The new design enhances stability in high-temperature and high-humidity environments, while also improving measurement accuracy, response time, and measurement range.
Each DHT20 sensor undergoes rigorous calibration and testing before shipment, ensuring consistent performance and reliability for large-scale applications.
Features:
- Fully calibrated
- Digital output, I2C interface
- Excellent long-term stability
- Quick response and strong anti-interference ability
- Wide voltage support: 2.2–5.5V DC
Specifications:
| Item Type | Sensor |
|---|---|
| Model Type | Temperature and Humidity Sensor |
| Rated Voltage (V) | 2.2 to 5.5 |
| Measuring Temperature (°C) | -40 ~ + 80 ℃ |
| Operating humidity | 0 ~ 100% RH |
| Measurement Accuracy | Humidity: ± 3 % RH (25 ℃), Temperature: ± 0.5 ℃ |
| Resolution | Temperature: 0.01℃, Humidity: 0.024%RH |
| Signal Output | I2C signal |
| Material | ABS |
Key Applications:
The DHT20 is a humidity and temperature sensor with digital I²C output. It can be applied to:
- HVAC systems
- Dehumidifiers
- Testing and inspection equipment
- Consumer products
- Automobiles
- Automatic control
- Data loggers
- Weather stations
- Home appliances
- Humidity control systems
- Medical devices
- And other application fields requiring temperature and humidity detection and control
Package Includes:
- 1 × DHT20 SIP Packaged Temperature and Humidity Sensor
Attachments:
Smoke Particle Counter: PM Sensor for Indoor Air Quality
Table of Contents Why Indoor Air Quality Matters Understanding PM2.5 and PM10 Types of PM and Smoke Sensors...
Read More →
Sensor Calibration Guide: Getting Accurate Readings Every Time
If you have ever built an Arduino project only to find that your sensor is reading 3°C higher...
Read More →
Gyroscope Sensor Guide: How It Works & Best Modules for Drones
A gyroscope sensor is the electronic heart of every modern drone, stabilized camera gimbal, self-balancing robot, and flight...
Read More →Technical Specifications
| Model | DHT20 |
|---|---|
| SKU | AI0540 |
| Weight | 0.0 kg |
| Availability | In Stock |
Applications & Use Cases
The DHT20 SIP Packaged Temperature and Humidity Sensor is a versatile temperature & humidity sensor used across a wide range of applications including weather stations, greenhouse monitoring, HVAC systems, cold chain logistics, and server room monitoring.
Common use cases:
- Building a home weather station with Arduino
- Monitoring greenhouse conditions via IoT
- Alerting when server room temperature exceeds threshold
This product is ideal for IoT developers, agricultural engineers, and home automation enthusiasts.
Technical Tip: DHT22 offers better accuracy than DHT11. For precision applications, use SHT31 or BME280. Ensure adequate ventilation around the sensor.
