The CNHL Black Series 2200mAh 4S 14.8V 40C LiPo battery is a popular choice among RC enthusiasts, particularly for use in drones, RC airplanes, helicopters, and other hobby-grade vehicles. Here’s a breakdown of its specifications:
- Capacity: 2200mAh (milliampere-hour) indicates the amount of charge the battery can hold. This capacity is suitable for powering medium-sized RC models and allows for decent flight or operation times.
- Voltage: 14.8V (volts) refers to the nominal voltage of the battery. This is a 4-cell battery pack, with each cell having a nominal voltage of 3.7V. When combined in series, they sum up to 14.8V.
- Discharge Rate (C-Rating): 40C indicates the discharge rate of the battery. The “C” rating is a measure of how much current the battery can deliver in relation to its capacity. In this case, it can provide a continuous discharge rate of up to 40 times its capacity (2200mAh), which is 88A (amps). This allows for high-performance maneuvers and power delivery for RC models that demand bursts of energy.
- Plug Type: The plug type is not specified in your query, but commonly, LiPo batteries come with different plug options such as XT60, Deans, EC3, or others, depending on the manufacturer’s specifications and user preference.
Overall, the CNHL Black Series 2200mAh 4S 14.8V 40C LiPo battery offers a balance between capacity, voltage, and discharge rate, making it suitable for various RC applications where moderate to high performance is required. As always, it’s essential to use the battery within its specified limits, adhere to proper charging and storage procedures, and follow safety guidelines to ensure longevity and prevent accidents.
Specification-
Capacity | 2200mAh | |||||
Voltage | 14.8V / 4-Cell / 4S1P | |||||
Discharge Rate | 40C Continual / 80C Burst | |||||
Charge Rate | 5C Max | |||||
Size(1-5mm difference) | 33.3X34.5X108mm | |||||
Approx Weight(±5g) | 256g | |||||
Output Connector | XT60 | |||||
Balance Connector | JST / XH | |||||
Remarks | N/A | |||||
Wire (AWG) | 12# |
package Include-
1 XÂ CNHL Black Series 2200mAh 4S 14.8V 40C Lipo Battery with XT60 Plug
