This is the 3V variant of the Arduino Pro Mini 328 – 3.3V/8 MHz in Boards Compatible with Arduino. Available at ₹116.82 (₹99.00 + GST) with free shipping across India.
Looking for Arduino Pro Mini 328? Arduino Pro Mini 328 – 3.3V/8 MHz is available at Zbotic with fast shipping across India.
Product Description
It’s blue! It’s thin! It’s the Arduino Pro Mini! SparkFun’s minimal design approach to Arduino. This is a 3.3V Arduino running the 8MHz bootloader. Arduino Pro Mini does not come with connectors populated so that you can solder in any connector or wire with any orientation you need. We recommend first time Arduino users start with the Uno R3. It’s a great board that will get you up and running quickly. The Arduino Pro series is meant for users that understand the limitations of system voltage (3.3V), lack of connectors, and USB off board.
We really wanted to minimize the cost of an Arduino. In order to accomplish this we used all SMD components, made it two layer, etc. This board connects directly to the FTDI Basic Breakout board and supports auto-reset. The Arduino Pro Mini also works with the FTDI cable but the FTDI cable does not bring out the DTR pin so the auto-reset feature will not work. There is a voltage regulator on board so it can accept voltage up to 12VDC. If you’re supplying unregulated power to the board, be sure to connect to the “RAW” pin on not VCC.
Feature:
- Onboard Power and Status LEDs
- USB connection off board
- Weighs less than 2 grams!
- Supports auto-reset
- Over current protected
- ATmega328 running at 8MHz with external resonator (0.5% tolerance)
- Low-voltage board needs no interfacing circuitry to popular 3.3V devices and modules (GPS, accelerometers, sensors, etc)
Package Includes :
- 1 x Arduino Pro Mini 328 – 3.3V/8 MHz
About Arduino Pro Mini 328
Arduino Pro Mini 328 – 3.3V/8 MHz is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Arduino, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Arduino
- SKU: AI1998
- Category: Boards Compatible with Arduino
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Arduino Pro Mini 328 and other products.
Applications
Arduino Pro Mini 328 can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Arduino Pro Mini 328 today and start building.
About Arduino Pro Mini 328
Arduino Pro Mini 328 – 3.3V/8 MHz is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Arduino, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Arduino
- SKU: AI1998
- Category: Other Measuring Instrument
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Arduino Pro Mini 328 and other products.
Applications
Arduino Pro Mini 328 can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Arduino Pro Mini 328 today and start building.
Arduino Pro Mini 328 – 3.3V/8 MHz Overview
The Arduino Pro Mini 328 – 3.3V/8 MHz is a compact, low-power development board based on the ATmega328 microcontroller. Designed for embedded projects, it runs at 8 MHz on a 3.3 V rail and features a minimal form factor without pre-soldered headers. This board is ideal for space-constrained applications where custom wiring and low-voltage operation are required.
Key Features of Arduino Pro Mini 328 – 3.3V/8 MHz
- ATmega328 microcontroller running at 8 MHz on 3.3 V for low-power operation
- On-board 3.3 V regulator with up to 150 mA output and over-current protection
- Wide DC input range from 3.3 V up to 12 V for flexible power sources
- Unpopulated pin headers allow custom connector orientation and soldering
- Slim, lightweight design measuring just 18 × 33 mm for tight enclosures
- Genuine Arduino Pro Mini shipped fast across India from Zbotic
Applications and Use Cases
- Battery-powered sensor nodes and wearable electronics
- Portable data loggers with custom input wiring
- Low-power robotics and drone subsystem controllers
- Remote control modules and wireless prototyping (requires separate radio)
- Compact home automation devices and environmental monitors
How to Use Arduino Pro Mini 328 – 3.3V/8 MHz
Solder your preferred pin headers or wires onto the unpopulated pads, connect a 3.3 V USB-to-serial adapter (FTDI) to VCC, GND, TX, RX and DTR, then select “Arduino Pro or Pro Mini (3.3V, 8 MHz)” in the Arduino IDE. Upload sketches as usual and power the board from an external supply between 3.3 V and 12 V to drive the regulator and onboard circuitry.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Do I need a USB cable to program the Pro Mini?
No, the Pro Mini lacks an onboard USB interface. You must use a 3.3 V FTDI or similar USB-to-serial adapter connected to VCC, GND, TX, RX and DTR to upload sketches.
Can I power the board from a Li-Po battery?
Yes. You can feed a Li-Po battery (3.7 V nominal) directly into the RAW input or regulated 3.3 V rail, keeping total board current under the 150 mA limit of the onboard regulator.
Are header pins included in the package?
No. The Arduino Pro Mini ships without pins soldered, allowing you to choose and position through-hole headers, right-angle connectors or direct wire soldering according to your project needs.
ATtiny85 Pinout, Programming & Projects: Complete Guide
Eight pins. One chip. Endless possibilities. The ATtiny85 is Microchip's smallest yet surprisingly capable AVR microcontroller — a...
Read More →
Arduino Modbus RTU Tutorial: Industrial Sensor Communication with RS485
If you're working on an industrial automation project or building a data-acquisition system, mastering Arduino Modbus RTU communication...
Read More →
Arduino Starter Kit Comparison: Best Kits to Buy in India 2026
Choosing the right Arduino starter kit in India can be the difference between a frustrating experience and an...
Read More →Technical Specifications
| Brand | Arduino |
|---|---|
| Operating Voltage | 3.3V |
| Frequency | 8 MHz |
| SKU | AI1998 |
| Weight | 0.003 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Arduino Pro Mini 328 – 3.3V/8 MHz is a versatile boards compatible with arduino used across a wide range of applications including electronics learning, robotics, home automation, sensor interfacing, and motor control.
Common use cases:
- Learning programming and electronics
- Building a line-following robot
- Creating a home automation hub
This product is ideal for students, hobbyists, and electronics beginners.
Technical Tip: Arduino Uno is the standard learning board. Mega offers more pins for complex projects. Nano suits breadboard prototyping.
