APM / PIXHAWK 3in1 Power Module ESC Distribution Board
100A Multirotor ESC Power Distribution Battery Board For Quadcopter
Features:
- Size: 50 x 50 x 4.5 mm.
- Mounted hole size: 4 x M3.
- Power input (V): DC 7 – 26.
- Suitable for APM 2.5, 2.6, 2.8 pixhawk.
- Suitable for Quadcopter Hexacopter Octocopter
- BEC Output: 3A 5V.
Specifications:
| Power Input (V) | 7 ~ 26 |
|---|---|
| BEC Output | 3A / 5V |
| Suitable for | APM 2.5, 2.6, 2.8 pixhawk |
| Battery connector | XT60 |
| Length (mm): | 50 |
| Width (mm): | 50 |
| Height (mm): | 7 |
| Weight (g): | 20 |
Package Includes:
1 x 3in1 Board.
1 x XT60 connector.
1x connecting cable.
APM / PIXHAWK 3in1 Power Module ESC Distribution Board Overview
The APM / PIXHAWK 3in1 Power Module ESC Distribution Board combines a power module, ESC power distribution and a 5V/3A BEC into one compact PCB. It’s designed to feed regulated power to APM 2.x and Pixhawk flight controllers while routing battery voltage to ESCs on quadcopters, hexacopters or octocopters.
Key Features of APM / PIXHAWK 3in1 Power Module ESC Distribution Board
- Input voltage DC 7–26 V (2S–6S LiPo) via included XT60 connector
- Integrated 5 V/3 A BEC output for flight controller and receiver
- Handles up to 100 A total current for high-power multirotor setups
- Compact dimensions (50 × 50 × 4.5 mm) with four M3 mounting holes
- Lightweight (20 g) design compatible with APM 2.5, 2.6, 2.8 and Pixhawk
- Fast shipping from Zbotic with genuine parts guaranteed
Applications and Use Cases
- Building or upgrading DIY quadcopters powered by APM or Pixhawk
- Power distribution for hexacopters and octocopters in aerial photography
- Prototyping custom multirotor frames requiring compact power management
- Replacing separate power modules and PDBs with an all-in-one solution
- Ensuring stable 5 V rail for flight controllers and onboard electronics
How to Use APM / PIXHAWK 3in1 Power Module ESC Distribution Board
Secure the board to your drone frame using M3 screws, solder ESC positive and negative wires to the distribution pads, and plug the XT60 connector into your battery. Connect the provided cable from the BEC output to the power input port on your APM or Pixhawk. Double-check polarity and mounting before powering up to ensure reliable operation.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the input voltage range and connector type?
This board accepts DC 7–26 V (2S–6S LiPo) via the included XT60 battery connector, covering most multirotor battery packs.
Which flight controllers are compatible?
It offers plug-and-play compatibility with APM 2.5, 2.6, 2.8 and Pixhawk through the supplied power module cable.
How many ESCs can I power with this distribution board?
The PCB provides power pads for quadcopter (4), hexacopter (6) and octocopter (8) configurations, allowing you to connect up to eight ESCs depending on your frame layout.
