SPECTER 1804-2450KV Motor
Description:
The SPECTER 1804-2450KV Motor is a high-performance brushless motor designed for remote-controlled drones and multirotor aircraft. With a KV rating of 2450, it offers efficient power and speed, making it suitable for agile maneuvers and swift flights. Its compact size, lightweight build, and durable construction contribute to improved flight dynamics and overall reliability, catering to both beginner and experienced pilots.
Technical Features:
- Motor model: 1804
- KV value: 2450KV
- Magnetic pole: 12N14P
- Magnetic steel: N52H
- Stator: Kawasaki 1200
- Rotor: 7075
- Bearing: ISC
- Winding: 260° high-temperature resistant copper wire
- Output shaft: M1.5×3.8mm
- Max current: 18A
- Max power: 432W
- voltage: 4-6S
- Outlet specification: 26AWG-150mm
- Suitable propeller: 3-3.5 inch
- Motor size: Φ22.68×13.2mm
- Mounting hole: 12×12（M2）
- Weight: 13.3g (including wire)
Specification:
| Specification | Value |
|---|---|
| Motor KV (RPM/V) | 2450KV |
| Max Current | 18A |
| Max Power | 432W |
| Bearing Type | ISC Bearing |
Features:
- Brand new rotor appearance design, an anodized two-color process
- 7075 aviation aluminum material, high-strength one-piece rotor
- Customized N52H curved magnetic steel, strong magnetism, large torque
- Super high temperature resistant 260° copper wire winding, the motor runs more stably
- Imported Kawasaki silicon steel sheets, low loss stator, reduce heat generation and improve efficiency
- New optimized adjustment and calibration, maintain high torque at low speed, linear power output when the throttle changes rapidly, precise and quick response when turning
- Titanium alloy shaft, high strength and reduce the weight of the drone
- Applicable to 3-3.5inch freestyle drones and 3-3.5inch racing drones
Package Includes:
1 x 1804-2450KV motor 5 x M2x6mm round head screw 2 x M2x7mm round head screw
