Description:
Skydroid G30 is a ground station remote controller for FPV drone operations featuring a 10.1-inch sunlight-readable HD display and a Qualcomm 6nm Android platform (Android 13). It supports hardware decoding of H.264/H.265 and 4K video streams for smooth use of ground station software. The system offers 2.4 GHz / 5.8 GHz dual-band links with automatic switching, up to 30KM remote control and video transmission (ground-to-air, line of sight), PD 33W fast charging, and rich wired interfaces including SIM, Ethernet, USB, Type-C/DP, PPM, and an FC fiber optic interface.
Key Features:
- 10.1-inch industrial touchscreen with 1920×1200 resolution; sunlight-readable.
- Qualcomm 6nm processor with Android 13; hardware decoding for H.264/H.265 and 4K streams.
- Long-range link: up to 30KM control and video transmission (ground-to-air, LOS).
- Dual-band 2.4 GHz / 5.8 GHz with automatic frequency hopping for robust, interference-resistant comms.
- HD digital video transmission for clear, real-time visuals.
- Fiber optic communication via FC interface; stable in complex electromagnetic environments.
- 20000 mAh battery, 4-6 hours typical battery life; PD 33W Type-C fast charging.
- Comprehensive I/O: USB, SIM card slot, Type-C/DP, Ethernet, PPM, FC fiber optic.
Specifications:
G30 Remote Controller Parameters
| Display Screen | 10.1-inch Industrial Touchscreen + Sunlight-Readable Display |
| Screen Resolution | 1920×1200 |
| Processor | Qualcomm 6nm Processor |
| Computer Type | Android 13 |
| Dimension | 346(L) x 196.5(W) x 89.4(H) mm |
| Weight | 1.5 kg |
| Battery | 20000 mAh |
| Battery Life | 4-6 hours |
| RAM | 8G |
| System Storage | 128G |
| Operating Frequency Band | 2.4 GHz / 5.8 GHz |
| Number of Channels | 16 |
| Dynamic Frequency Band | Automatic Frequency Hopping |
| RF Power | 23 dBm |
| Remote Control Range | 5-30 KM (Ground-to-Air, Line of Sight) |
| Operating Temperature | -10°C to 55°C |
| Fiber Optic Range | 20 KM |
| Charging Interface | Type-C |
| External Interfaces | USB Port, SIM Card Slot, Type-C/DP Port, Ethernet Port, PPM Port, FC Port |
GR03 Receiver Parameters
| Operating Frequency Band | 2.4 GHz / 5.8 GHz |
| Serial Port Baud Rate | 57600 / 115200 / 921600 |
| Supply Voltage | 7.2V-72V (XT30) |
| Working Current | 12V / 350 mA |
| Data Transmission Port | 2 channels |
| SBUS Input | 1 channel |
| Ethernet Port | 2 channels |
| Dimension | 58.7 x 82 x 20 mm |
| FC Interface | 1 channel |
| Weight | 1.5 kg |
| PWM Interface | 3 channels |
| Working Temperature | -10°C to 60°C |
| Audio Output | 1 channel |
| RF Power | 23 dBm @ CE/FCC |
| Transmission Rate | 10 Mbps downstream, 200 kbps upstream |
| Channel Bandwidth | 10 Mbps downstream, 2.5 Mbps upstream |
Details
Skydroid G30 GR03 large-screen remote controller with fiber optic interface
10-inch HD display, Qualcomm 6nm processor, 30KM transmission, fiber optic communication, Android 14, dual-band auto-switching, fast charging.
Qualcomm Android Platform with 6nm processor, Android 13, supports H.264/H.265 and 4K video decoding for seamless ground station software operation.
10.1-inch HD screen, 1920×1200 resolution, sunlight-readable, responsive touchscreen, sharp visuals, clear visibility in strong light.
Fast charging, extended battery life, 33W PD support, reduced power consumption and heat.
30KM remote control and video transmission with proprietary data-video-control link technology.
G30 supports 2.4GHz/5.8GHz dual bands with automatic switching, stable signal, efficient transmission, and strong anti-interference performance. (28 words)
HD Video Transmission, G30 supports long-range high-definition digital video transmission.
G30 uses FC interface for ultra-high-speed data transfer, immune to electromagnetic interference, ensuring stable performance in fiber optic communication. (28 words)
G30 offers SIM, Ethernet, USB, Type-C/DP, PPM, and FC fiber ports for versatile, adaptable connectivity in diverse applications. (26 words)
10.1-inch Android 13 touchscreen, 8GB RAM, 128GB storage, 20000mAh battery. Supports 2.4/5.8GHz, 16 channels, 5-30KM range. Includes USB, Ethernet, TYPE-C. GR03 receiver: dual-band, 2 data/Ethernet, 1 FC, 3 PWM channels. (39 words)
