IRLR7843TRPBF MOSFET
Introducing the IRLR7843TRPBF MOSFET by Infineon Technologies. This MOSFET, housed in a standard TO-220 package with a fast-on tab, is engineered for easy handling and versatile usage in power management applications.
This MOSFET offers a Drain to Source Voltage (Vdss) of 30V and a continuous drain current (Id) of 161A at 25°C (Tc), making it suitable for high-power requirements. With drive voltage specifications of 4.5V (Max Rds On) and 10V (Min Rds On), it ensures compatibility with various circuit configurations.
Reliable and stable performance makes it ideal for applications such as DC-DC converters, switching power supplies, and motor drives. Upgrade your power management systems with the IRLR7843TRPBF MOSFET for efficient and dependable operation.
Features:
- Easy to use
- Easy to handle
- Can be used in various power management applications
Specifications:
| Package/Case | Tape & Reel (TR) | Cut Tape (CT) |
|---|---|
| Standard Package | 2000 |
| Item Type: | N-Channel FET |
| Technology | MOSFET (Metal Oxide) |
| Current – Continuous Drain (Id) @ 25°C | 161A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3.3m Ohm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2.3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 50 nC @ 4.5 V |
| Vgs (Max) | 320 V |
| Input Capacitance (Ciss) (Max) @ Vds | 4380 pF @ 15 V |
| Power Dissipation (Max) | 140W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | D-Pak |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Base Product Number | IRLR7843 |
| Drain to Source Voltage (Vdss) | 30 V |
Package Includes:
1 x IRLR7843TRPBF MOSFET
Technical Specifications
| Model | IRLR7843TRPBF |
|---|---|
| SKU | AI1386 |
| Weight | 0.0 kg |
| Availability | In Stock |
Applications & Use Cases
The IRLR7843TRPBF MOSFET is a versatile mosfet ics used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
