This is the CCW rotation variant of the Hobbywing X13 Motor with 5620 Propeller Combo-CCW in Drone Kit, Drone Parts. Available at ₹47,781.25 (₹45,505.95 + GST) with free shipping across India.
Hobbywing X13 Motor with 5620 Propeller Combo-CCW
Description:
The Hobbywing X13 motor is a high-performance 18S agriculture drone motor designed for heavy-lift UAVs in India. With up to 57kg thrust per rotor, the X13 motor is ideal for 20L, 30L, and 50L spray drones.
A high-quality X13 motor ensures maximum thrust, longer flight time, and stable spraying operations across large farms.
For agriculture drone manufacturers, drone service providers, and UAV engineers, the need for a reliable heavy-lift drone motor is non-negotiable. Weak motors reduce efficiency, drain batteries faster, and compromise spray quality — which is why professionals prefer the Hobbywing X13 motor with 5620 propeller combo.
Engineered for demanding applications, the Hobbywing X13 motor delivers up to 57 kg thrust per arm, supports 18S high-voltage battery systems, and features CAN bus communication for intelligent flight control integration. This makes it one of the best drone motors for agriculture drones, especially for 20L, 30L, and 50L spraying drones.
If you are searching for the best X13 motor for agricultural drones, a high-performance drone motor, or a heavy-lift UAV propulsion system in India, the Hobbywing X13 motor with 5620 propeller is a proven, professional-grade choice built for serious operations.
Key Features of the Hobbywing X13 Motor with 5620 Propeller Combo
- Massive 57 kg Thrust Per Arm — Lift heavier payloads with confidence, ideal for 20L, 30L, and 50L agriculture drones.
- 18S High-Voltage System — Operates on 18S LiPo battery packs (≈75.6V nominal), delivering superior efficiency and reduced current draw.
- CAN Bus Communication — Two-way data exchange between motor/ESC and flight controller for real-time RPM feedback, fault diagnostics, and intelligent throttle response.
- 5620 Carbon Fibre Propeller — Precision-balanced, 56-inch class propeller engineered specifically to match the X13 motor’s thrust curve.
- Integrated Motor + ESC + Propeller Combo — Plug-and-play package eliminates compatibility headaches and reduces build time.
- Advanced Cooling Design — Optimized heat dissipation enables sustained high-load operation without thermal throttling.
- IP-Rated Protection — Dust and chemical-resistant design built to survive pesticide spray exposure and Indian field conditions.
- High-Efficiency Brushless Motor — Maximises thrust-per-watt for extended flight time on every battery cycle.
- Smart ESC with Active Braking — Faster motor response, smoother attitude control, and improved spray pattern stability.
- Industrial-Grade Build Quality — Hobbywing’s proven engineering trusted by leading global drone manufacturers.
Specifications :
Motor — X13 18S
| Parameter | Specification |
|---|---|
| Motor | X13 18S |
| Stator Size | Φ138 × 25 mm |
| KV Rating | 45 rpm/V |
| Recommended Battery | 18S LiPo |
| Maximum Thrust (Sea Level) | 57 kg/rotor |
| Rated Thrust | 27 kg/rotor |
| Recommended Takeoff Weight | 25–27 kg/rotor |
| Arm Tube Outer Diameter | 50 mm |
| Bearing Type | Waterproof Sealed |
| Operating Temperature | −20 °C to +50 °C |
| Ingress Protection | IPX6 |
| Rotation | CW & CCW |
| Total Weight (Including Propeller) | 4,087 g |
ESC — 200A 18S
| Parameter | Specification |
|---|---|
| ESC | 200A 18S |
| Rated Current | 200 A |
| Maximum Input Voltage | 81 V |
| Rated Power Input | 3,500 W |
| Rated Power Output | 3,000 W |
| PWM Signal Level | 3.3 V / 5 V |
| Throttle Signal Frequency | 50–500 Hz |
| Operating Pulse Width | 1050–1950 µs |
| BEC Output | No |
| Protocol Support | PWM + CAN Bus |
Propeller — MFP 56×20
| Parameter | Specification |
|---|---|
| Propeller | MFP 56×20 |
| Diameter × Pitch | 56 × 20 in |
| Material | Multi-Composite Fibre |
| Compatibility | 14S & 18S X13 |
| Peak Efficiency @ 18S | 12.7 g/W |
| Maximum Thrust @ 100% | 58,749 g |
18S Load Performance Data — 70V (MFP 56×20)
18S · 70V · Sea Level · 25°C
| Throttle | Thrust (g) | Current (A) | Power In (W) | Speed (RPM) | Efficiency (g/W) | Torque (N·m) | Power Out (W) |
|---|---|---|---|---|---|---|---|
| 33% | 9,514 | 10.9 | 749 | 1,004 | 12.7 | 6.28 | 661 |
| 39% | 13,287 | 17.2 | 1,190 | 1,183 | 11.2 | 8.65 | 1,072 |
| 45% | 17,812 | 26.1 | 1,803 | 1,364 | 9.9 | 11.39 | 1,627 |
| 51% | 22,693 | 36.9 | 2,551 | 1,532 | 8.9 | 14.29 | 2,293 |
| 57% | 27,794 | 49.6 | 3,423 | 1,688 | 8.1 | 17.33 | 3,063 |
| 63% | 33,118 | 64.3 | 4,437 | 1,836 | 7.5 | 20.54 | 3,948 |
| 72% | 41,557 | 91.1 | 6,290 | 2,050 | 6.6 | 25.69 | 5,516 |
| 81% | 50,109 | 123.5 | 8,525 | 2,248 | 5.9 | 30.92 | 7,280 |
| 90% | 56,981 | 153.4 | 10,595 | 2,396 | 5.4 | 35.10 | 8,805 |
| 100% | 58,749 | 161.7 | 11,164 | 2,433 | 5.3 | 36.18 | 9,215 |
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Hobbywing X13 Motor with 5620 Propeller Combo |
| Motor Type | Brushless Outrunner (Agriculture/Industrial Grade) |
| Maximum Thrust | Approx. 57 kg per arm |
| Battery Compatibility | 18S LiPo (≈75.6V nominal) |
| Propeller | 5620 Carbon Fibre (56-inch class) |
| ESC | Integrated Hobbywing Smart ESC |
| Communication Protocol | CAN Bus (two-way data) |
| Cooling | Active heat dissipation design |
| Protection Rating | Dust & chemical-resistant |
| Recommended Use | 20L, 30L, 50L agriculture drones, heavy-lift UAVs |
| Combo Includes | Motor + ESC + 5620 Propeller (per arm) |
| Country of Origin | Imported – Supported & Shipped in India |
| Ideal For | Drone manufacturers, OEMs, agri-tech businesses, industrial UAV builders |
Applications:
The Hobbywing X13 18S motor and 5620 propeller combo is the propulsion choice for the most demanding drone applications in India:
- 20L Agriculture Spraying Drones Comfortable thrust margin for fully loaded 20L spraying systems.
- 30L Agriculture Spraying Drones — Optimal match for heavy mid-tier commercial spraying platforms.
- 50L Agriculture Spraying Drones — Powers the largest commercial drones for plantation and estate spraying.
- Heavy-Lift Industrial UAVs — Surveying, mapping, and inspection drones carrying heavy payloads.
- Cargo & Logistics Drones — Last-mile delivery UAVs for parcels, medical supplies, and equipment.
- Aerial Cinematography Heavy Rigs — Powering large camera platforms with cinema gear.
- Firefighting & Emergency Drones — Lifting water tanks, retardant, or rescue payloads.
- Construction & Mining UAVs — Heavy-duty inspection and survey platforms.
- Government & Defense Applications — Reliable propulsion for mission-critical heavy-lift operations.
Package Includes:
1xHobbywing X13 Motor with 5620 Propeller Combo-CCW
