This is the 12V variant of the DC12V 750GPH Bilge Pump in Generic Mini Pumps. Available at ₹859.04 (₹728.00 + GST) with free shipping across India.
Looking for Dc12v 750gph Bilge? DC12V 750GPH Bilge Pump is available at Zbotic with fast shipping across India.
Product Description
This pump is a high-quality submersible bilge pump with a powerful magnetic motor made of rare earth materials and pure copper coils that can resist high temperatures. The pump has a silent and ignition-proof impeller that is enclosed in an ABS motor housing to protect it. The motor housing is also sealed in a sturdy and waterproof AB enclosure that has a removable and spring-loaded filter for easy cleaning.
Applications:
- Medical Purpose
- Research Purpose
- Solar Water System
- Swimming Pool Pumping.
Features:
- Rare Earth Strong Magnet Motor
- Three-Piece Impeller
- Moisture-Proof Sealed Enclosure Made From Solid ABS
- Detachable Spring Loaded Filter
- Stainless steel shaft
- Rust & cotrrosion protection
Specification-
| Product | Bilge Pump |
|---|---|
| Model | CH8028 |
| Flow Rate | 750GPH |
| Voltage | 12V |
| Current | 3.0A |
| Color | Red, White, Blue |
| Material | ABS Plastic |
| Cable Length | 102cm |
| Product Weight | 340 |
| Shipping Weight | 0.374 kg |
| Shipping Dimensions | 10 × 9 × 12 cm |
Package Includes:
1 x DC12V 750GPH Bilge Pump
DC12V 750GPH Bilge Pump Overview
The DC12V 750GPH Bilge Pump (Model CH8028) is a compact, submersible pump designed for reliable water removal in a variety of settings. Powered by a 12V DC supply, it delivers efficient, high-volume flow in a robust, sealed housing.
Key Features of DC12V 750GPH Bilge Pump
- High-strength rare earth magnet motor for long-lasting performance
- Pure copper coils that resist high operating temperatures
- Silent, ignition-proof three-piece impeller enclosed in ABS
- Waterproof ABS enclosure with a removable, spring-loaded filter
- Submersible design ensures stable operation below the waterline
- Fast shipping across India from Zbotic
Applications and Use Cases
- Medical equipment water circulation
- Research laboratory fluid handling
- Solar-powered water systems
- Swimming pool and spa drainage
How to Use DC12V 750GPH Bilge Pump
Place the pump fully submerged in the water source, secure it to a stable surface, and attach a 19 mm outlet hose. Connect the pump’s red and black leads to a 12V DC power supply rated at 3 A, ensuring proper polarity. Switch on the power and monitor the flow; periodically remove the pump to clean the spring-loaded filter cap.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What power requirements does this bilge pump have?
The pump runs on DC 12 V at up to 3 A. Use a stable 12 V DC power source capable of supplying the full current rating for optimal performance.
How do I clean the filter on the pump?
Unscrew the spring-loaded filter cap located at the inlet. Rinse out debris under running water, reattach the filter assembly, and ensure it seals securely before submerging the pump again.
Can the DC12V 750GPH Bilge Pump operate continuously?
Yes. Its sealed ABS enclosure and temperature-resistant copper coils allow for continuous duty. For long-term use, inspect and clean the filter periodically to maintain peak flow.
