Looking for Imx327 Motor? Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Camera for Raspberry Pi is available at Zbotic with fast shipping across India.
The camera uses the Sony Low Light STARVIS IMX327 sensor which is a diagonal 6.46 mm (Type 1/2.8) CMOS active pixel type solid-state image sensor with a square pixel array and 2.13 million effective pixels. The chip uses analog 2.9 V, digital 1.2 V, and interface 1.8 V. This highly sensitive low-light camera can capture extremely sharp images with minimal noise at extremely low light conditions. It features low power consumption, high functionality, high sensitivity, low dark current and no smear. The sensor applies R, G, and B primary color mosaic filters, as well as a variable electronic shutter.
APPLICATIONS:
- Surveillance cameras
- FA cameras
- Industrial cameras
- Autonomous mobile robots, UGV/UAV, ADAS, etc.
Features:
- Input frequency: 74.25 MHz / 37.125 MHz
- Pixels: Approx. 1920 (H) × 1080 (V) 2.07 million pixels
- Maximum frame rate in Full HD 1080p mode: 30 fps
- Wide Dynamic Range (WDR) function: Multiple exposure WDR, Digital Overlay WDR
- 10-bit/12-bit A/D converter
- CSI-2 serial data output: 2 Lane, RAW10 / RAW12 output
Specifications:
- Sensor: SONY STARVIS IMX327
- Optical Size: Type 1/2.8” (Diagonal 6.46 mm)
- Pixel Size: 2.9μm×2.9μm
- Shutter Type: Rolling Shutter
- Max Sensor Resolution: 1920 x 1080
- Color Filter Array: Bayer RGB
- Resolution and Frame Rate: RAW10: 1920×1080@46fps;1280×720@90fps, RAW12:1920×1080@46fps;1280×720@90fps
- Supported Platform: Pi 4/3/Zero/CM3/CM4
- Output Format: RAW10/RAW12
- Focus Type: Manual
- Lens Mount: M12 Mount
- F.NO: 1.6±10%
- MOD: 2.0
- Effective Focal Length: 4.3±5%mm
- Back Focal Length: 5.43±0.2mm
- FOV(Field of View): 80°H
- IR Sensitivity: Motorized IR-CUT
- Camera Board Size: 38mmx38mm
Package Includes:
1 x IMX327 Motorized IR-CUT Camera Module
1 x 150mm 15pin to 22pin flex cable
About Imx327 Motor
Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Camera for Raspberry Pi is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Raspberry Pi, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Raspberry Pi
- SKU: AI1877
- Category: Arducam Cameras and Accessories
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Imx327 Motor and other products.
Applications
Imx327 Motor can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Imx327 Motor today and start building.
About Imx327 Motor
Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Camera for Raspberry Pi is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Raspberry Pi, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.
Product Details
- Brand: Raspberry Pi
- SKU: AI1877
- Category: HMI LCD Display
Why Buy from Zbotic?
Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Imx327 Motor and other products.
Applications
Imx327 Motor can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Imx327 Motor today and start building.
Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Overview
The Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Camera is a high-sensitivity imaging module designed specifically for Raspberry Pi. Featuring Sony’s STARVIS IMX327 sensor and a motorized IR-cut filter, it captures sharp, low-noise footage in both daylight and near-dark conditions.
Key Features of Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT
- Ultra-Low Light Sensor: Sony STARVIS IMX327 sensor delivers clear images in minimal lighting.
- Motorized IR-CUT Filter: Automatically switches between infrared and visible light modes.
- High Frame Rates: Up to 90 fps at 1280×720 and 46 fps at 1920×1080 for smooth video.
- Raspberry Pi Native: Plug-and-play via the CSI interface—no additional drivers needed.
- Low Power & Noise: Energy-efficient design with minimal dark current and smear.
- Fast Shipping from Zbotic: Prompt delivery across India ensures you get your camera quickly.
Applications and Use Cases
- 24/7 home and office surveillance with clear night vision
- Wildlife monitoring and time-lapse photography in low light
- Robotics vision systems operating under variable lighting
- Smart doorbell or access-control camera for Raspberry Pi projects
- Industrial inspection in dimly lit environments
How to Use Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT
Simply attach the camera module to your Raspberry Pi’s CSI port, enable the camera interface via raspi-config, and reboot. Use Raspberry Pi OS’s built-in libcamera or OpenCV libraries to capture images or video. The motorized IR-cut filter will automatically adjust based on ambient light, so you can focus on coding your application rather than manual adjustments.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Do I need a separate driver to use this camera on Raspberry Pi?
No. The Arducam IMX327 module is fully compatible with Raspberry Pi OS and uses the native camera interface—no additional drivers are required.
How does the motorized IR-cut filter operate?
The onboard controller automatically retracts or engages the IR-cut filter based on ambient lighting. In low light, the filter moves aside to allow infrared, and it returns in bright conditions for true-color imaging.
What frame rates can I expect at different resolutions?
You can achieve up to 90 fps at 1280×720 resolution and 46 fps at 1920×1080 resolution, making it suitable for smooth, high-speed video capture.
Technical Specifications
| Brand | Raspberry Pi |
|---|---|
| Package Quantity | 327 pcs |
| SKU | AI1877 |
| Weight | 0.007 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Arducam 2MP Ultra Low Light STARVIS IMX327 Motorized IR-CUT Camera for Raspberry Pi is a versatile arducam cameras and accessories used across a wide range of applications including computer vision, surveillance, machine learning inference, time-lapse photography, and barcode scanning.
Common use cases:
- Adding vision to a Raspberry Pi robot
- Building a wildlife camera trap
- Implementing QR code scanning in a project
This product is ideal for computer vision developers and Raspberry Pi enthusiasts.
Technical Tip: Arducam cameras support various interfaces (MIPI CSI, USB, SPI). Higher megapixel count improves detail but increases processing requirements.
