Looking for Lcb50 Connector? AMASS LCB50-F connector is available at Zbotic with fast shipping across India.
The AMASS LCB50-F is a female straight plug, 2-pin, high-current DC power connector from the LC series by AMASS (Changzhou Amass Elec). It is engineered for high-demand applications such as large-format lithium battery packs, electric vehicles, industrial drones, and power tools, where secure connectivity, high current capacity, and reliability under vibration and harsh conditions are essential.
Constructed with a durable orange housing (also available in other colors) and silver-plated, high-conductivity copper contacts, the connector ensures low resistance and efficient power transfer. Its “strong-lock” mating mechanism provides a secure, vibration-resistant connection, minimizing the risk of contact loss, heating, or electrical failure during operation.
The LCB50-F is typically cable-mounted (not PCB-mounted) and pairs with its matching male counterpart for high-current applications. With its flame-retardant UL94 V-0 housing, wide temperature tolerance, and mechanical durability, it is perfectly suited for industrial, automotive, and aerospace-grade systems where stability and safety are critical.
Lcb50 Connector – Key Features:
- High-current 2-pin female plug for demanding power systems
- Silver-plated copper contacts for optimal conductivity and low resistance
- Strong-lock design ensures reliable contact under vibration and motion
- Cable-mount configuration for flexible installation
- Flame-retardant UL94 V-0 plastic housing for enhanced safety
- Wide operating temperature range: -40 °C to +120 °C
- Ideal for lithium battery packs, EVs, drones, and industrial tools
Usage Notes:
- Pair only with the matching AMASS male connector (same series and rating)
- Match wire gauge appropriately (e.g., 8 AWG / 10 AWG) for current capacity
- Ensure environmental conditions (vibration, temperature, dust) are within rating limits
- Follow manufacturer-rated mating cycles to maintain connection integrity
- Refer to the official datasheet for detailed specs like voltage rating, insulation resistance, and mechanical performance
Specifications:
| Manufacturer | AMASS |
|---|---|
| Type of Connector | DC Supply |
| Connector | Plug |
| Kind of Connector | Female |
| Manufacturer Series | LC |
| Current Rating | 40A |
| Rated Voltage | 1kV |
| Number of Pins | 2 |
| Spatial Orientation | Straight |
| Mechanical Mounting | For Cable |
| Electrical Mounting | Soldering |
| Contact Material | Copper |
| Contact Plating | Silver Plated |
| Colour | Orange |
| Flammability Rating | UL94V-0 |
| Wire Size | 10AWG…8AWG |
| Mechanical Durability | 1000 Cycles |
| Operating Temperature | -40…120°C |
Package Includes:
- 1x AMASS LCB50-F connector
AMASS LCB50-F connector Overview
The AMASS LCB50-F connector is a female straight plug with a 2-pin layout, designed for high-current DC power connections. It is engineered for demanding applications such as large-format lithium battery packs, electric vehicles, industrial drones, and power tools where secure, vibration-resistant performance is essential.
Key Features of AMASS LCB50-F connector
- Female straight plug with 2-pin layout for reliable DC power delivery
- Rated for 40 A continuous current and 1 kV DC voltage
- Silver-plated copper contacts ensure low resistance and high conductivity
- Cable-mount design with robust housing, withstands –40 °C to +120 °C
- Strong-lock mating mechanism for secure, vibration-resistant connections
- Fast shipping across India from Zbotic
Applications and Use Cases
- Large-format lithium battery packs in energy storage systems
- Power distribution in electric vehicles and e-bikes
- High-performance industrial and professional drones
- Battery connections in cordless power tools and outdoor equipment
- Renewable energy installations like solar inverters
- RC models and hobbyist electric vehicle setups
How to Use AMASS LCB50-F connector
To install the AMASS LCB50-F connector, select a cable rated for 40 A and strip the insulation to expose the conductor. Crimp or solder the conductor onto the silver-plated copper contacts, then press the contacts into the orange housing until they lock. Route the cable to provide strain relief, then mate the connector with its male counterpart—listen for the audible click of the strong-lock mechanism to confirm a secure, vibration-resistant connection.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What current and voltage ratings does the AMASS LCB50-F connector support?
The AMASS LCB50-F is rated for up to 40 A continuous current and 1 kV DC voltage, making it suitable for high-power applications.
Can the AMASS LCB50-F connector be mounted on a PCB?
No, the LCB50-F is designed exclusively for cable mounting and is not compatible with PCB installation.
What temperature range can the AMASS LCB50-F operate in?
The connector reliably operates in environments from –40 °C up to +120 °C, ensuring performance under harsh conditions.
